San Ace 120W Splash Proof Fan 9WG1212M101-E

Name: San Ace 120W Splash Proof Fan 9WG1212M101-E
Brand: Marsh Electronics, Inc.
SKU: SAN-ae7d42
Price: 29.99 USD
Availability: OutOfStock

SKU:SAN-ae7d42

Enhance equipment performance with the San Ace 120W Splash Proof Fan for reliable industrial cooling. Durable design, low noise, high efficiency.

$29.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The San Ace 120W Splash Proof Fan 9WG1212M101-E is a high-performance cooling solution designed for industrial applications. With a durable aluminum frame and UL94V-1 rated plastics impeller, this fan ensures reliable operation in challenging environments. Operating at a voltage range of 7 to 13.8V, it delivers consistent airflow of 2.10 m³/min with low noise levels. The fan's sturdy construction, rated for 100,000 hours at 60ºC, makes it a dependable choice for demanding settings.

Product Specifications

Specifications Air Flow

2.10 mÂ³/min | 74 ftÂ³/min

Specifications Anode Lead Wire Color

Red

Specifications Cathode Lead Wire Color

Black | Blue

Specifications Dimensions

120 x 120 x 38 mm

Specifications Expected Life At 60c

100000 hours

Specifications Frame Material

Aluminum

Specifications Impeller Material

Plastics (Flammability: UL94V-1)

Specifications Mass

410 g

Specifications Non Condensing Storage Temperature

-30 to +70 ÂºC

Specifications Operating Temperature Range

-20 to +70 ÂºC

Specifications Operating Voltage Range

7 to 13.8 V

Specifications Rated Current

0.21 A

Specifications Rated Input Power

2.52 W

Specifications Rated Speed

1950 rpm

Specifications Rated Voltage

12 V

Specifications Sensor Lead Wire Color

Yellow

Specifications Sound Pressure Level

32 dBA

Specifications Static Pressure

39.6 Pa | 0.159 inH2O

San Ace 120W Splash Proof Fan 9WG1212M101-E
