San Ace 120WS Splash Proof Fan - 24V DC 120x120x38mm
San Ace 120WS Splash Proof Fan - 24V DC 120x120x38mm
SKU:SAN-d01473
Reliable and durable San Ace 120WS Splash Proof Fan for industrial cooling needs, 24V DC, 1950 rpm, UL94V-0 & UL94V-1 compliant
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Initiate Order
San Ace 120WS Splash Proof Fan - 24V DC 120x120x38mm
$29.99
Quantity: 1
Claim Your Seller Account
San Ace 120WS Splash Proof Fan - 24V DC 120x120x38mm
$29.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The San Ace 120WS Series Splash Proof Fan is a reliable cooling solution designed for industrial and institutional applications. With a durable plastic frame and impeller meeting UL94V-0 and UL94V-1 flammability standards, this fan ensures safety and performance. Operating at 24V with a rated speed of 1950 rpm, it delivers a maximum airflow of 2.20m³/min and a maximum static pressure of 42.14 Pa. With a noise level of only 32 dBA and an expected life of 40,000 hours, this fan offers efficient and long-lasting cooling for demanding environments.
Product Specifications
Specifications Anode Lead Wire Color
Red
Specifications Cathode Lead Wire Color
Black | Blue
Specifications Dimensions
120 x 120 x 38 mm
Specifications Expected Life At 60c
40,000 hours
Specifications Frame Material
Plastics (Flammability: UL94V-0)
Specifications Impeller Material
Plastics (Flammability: UL94V-1)
Specifications Mass
260 g
Specifications Maximum Air Flow
2.20 m³/min | 77.7 ft³/min
Specifications Maximum Static Pressure
42.14 Pa | 0.169 inH2O
Specifications Non Condensing Storage Temperature
-30 to +70 ºC
Specifications Operating Temperature Range
-20 to +70 ºC
Specifications Operating Voltage Range
12 to 27.6 V
Specifications Rated Current
0.13 A
Specifications Rated Input Power
3.12 W
Specifications Rated Speed
1950 rpm
Specifications Rated Voltage
24 V
Specifications Sensor Lead Wire Color
Yellow
Specifications Sound Pressure Level
32 dBA
