San Ace 140W Series Splash Proof Fan - 140 x 140 x 51 mm, 48V, 3,100 rpm
San Ace 140W Series Splash Proof Fan - 140 x 140 x 51 mm, 48V, 3,100 rpm
SKU:SAN-e530a6
Efficient and durable San Ace 140W splash-proof fan for reliable cooling in a range of environments.
Regular price
$59.99
Regular price
Sale price
$59.99
Unit price
per
Initiate Order
San Ace 140W Series Splash Proof Fan - 140 x 140 x 51 mm, 48V, 3,100 rpm
$59.99
Quantity: 1
Claim Your Seller Account
San Ace 140W Series Splash Proof Fan - 140 x 140 x 51 mm, 48V, 3,100 rpm
$59.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The San Ace 140W Series Splash Proof Fan is designed for durability and efficiency, featuring a robust aluminum frame and UL94V-1 rated plastics impeller. With a rated voltage of 48V, this fan operates within an extensive temperature range, ensuring reliable performance in various environments. Delivering a maximum air flow of 5.9 m³/min and a sound pressure level of 49 dBA, it offers efficient cooling with minimal noise. With a long expected lifespan of 100,000 hours at 60°C, this fan is a cost-effective solution for cooling systems in both consumer and institutional settings.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Specifications Anode Lead Wire Color
Red
Specifications Cathode Lead Wire Color
Black | Blue
Specifications Dimensions
140 x 140 x 51 mm
Specifications Expected Life At 60c
100000 hours
Specifications Frame Material
Aluminum
Specifications Impeller Material
Plastics (Flammability: UL94V-1)
Specifications Mass
700 g
Specifications Maximum Air Flow
5.9 m³/min | 208.5 ft³/min
Specifications Maximum Static Pressure
130 Pa | 0.52 inH2O
Specifications Non Condensing Storage Temperature
-30 to +70 ºC
Specifications Operating Temperature Range
-20 to +70 ºC
Specifications Operating Voltage Range
40.8 to 55.2 V
Specifications Rated Current
0.27 A
Specifications Rated Input Power
12.96 W
Specifications Rated Speed
3,100 rpm
Specifications Rated Voltage
48 V
Specifications Sensor Lead Wire Color
Yellow
Specifications Sound Pressure Level
49 dBA
