San Ace 140W Splash Proof Fan
San Ace 140W Splash Proof Fan
SKU:SAN-40b26f
High-performance San Ace 140W Splash Proof Fan for industrial & commercial applications. Dimensions: 140x140x38mm, Aluminum frame, UL94V-1 rated plastics impeller, 24V, 2600 rpm, 4.5 m³/min airflow, -20 to +70 °C operating temp, 100,000-hour lifespan.
Regular price
$45.99
Regular price
Sale price
$45.99
Unit price
per
Initiate Order
San Ace 140W Splash Proof Fan
$45.99
Quantity: 1
Claim Your Seller Account
San Ace 140W Splash Proof Fan
$45.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The San Ace 140W Splash Proof Fan is a high-performance cooling solution designed for industrial and commercial applications. With dimensions of 140 x 140 x 38 mm and a robust aluminum frame, this fan ensures durability and efficient heat dissipation. Its UL94V-1 rated plastics impeller offers excellent fire resistance. Operating at 24V with a rated speed of 2600 rpm, it delivers a maximum airflow of 4.5 m³/min. This fan is built to withstand extreme conditions with an operating temperature range of -20 to +70 °C and an expected lifespan of 100,000 hours at 60°C.
Product Specifications
Specifications Anode Lead Wire Color
Red
Specifications Cathode Lead Wire Color
Black | Blue
Specifications Dimensions
140 x 140 x 38 mm
Specifications Expected Life At 60c
100000 hours
Specifications Frame Material
Aluminum
Specifications Impeller Material
Plastics (Flammability: UL94V-1)
Specifications Mass
650 g
Specifications Maximum Air Flow
4.5 m³/min | 159 ft³/min
Specifications Maximum Static Pressure
98 Pa | 0.394 inH2O
Specifications Non Condensing Storage Temperature
-30 to +70 ºC
Specifications Operating Temperature Range
-20 to +70 ºC
Specifications Operating Voltage Range
20.4 to 27.6 V
Specifications Rated Current
0.37 A
Specifications Rated Input Power
8.88 W
Specifications Rated Speed
2600 rpm
Specifications Rated Voltage
24 V
Specifications Sensor Lead Wire Color
Yellow
Specifications Sound Pressure Level
46 dBA
