San Ace 140W Splash Proof Fan 140x140x38mm, 24V
San Ace 140W Splash Proof Fan 140x140x38mm, 24V
SKU:SAN-ad7d69
The San Ace 140W Splash Proof Fan: Durable, reliable cooling for industrial environments. 140x140x38mm, 24V.
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Initiate Order
San Ace 140W Splash Proof Fan 140x140x38mm, 24V
$29.99
Quantity: 1
Claim Your Seller Account
San Ace 140W Splash Proof Fan 140x140x38mm, 24V
$29.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The San Ace 140W Series Splash Proof Fan is a high-quality cooling solution designed for durable performance in challenging environments. With a robust aluminum frame and UL94V-1 rated plastic impeller, this fan ensures reliable operation. Operating within a wide voltage range of 20.4 to 27.6V, it delivers an airflow of 3.30 m³/min and a maximum static pressure of 52 Pa. Ideal for industrial and institutional applications, this fan offers a long service life of 100,000 hours at 60ºC, meeting stringent reliability standards.
Product Specifications
Specifications Anode Lead Wire Color
Red
Specifications Cathode Lead Wire Color
Black | Blue
Specifications Dimensions
140 x 140 x 38 mm
Specifications Expected Life At 60c
100000 hours
Specifications Frame Material
Aluminum
Specifications Impeller Material
Plastics (Flammability: UL94V-1)
Specifications Mass
650 g
Specifications Maximum Air Flow
3.30 m³/min | 117 ft³/min
Specifications Maximum Static Pressure
52 Pa | 0.209 inH2O
Specifications Non Condensing Storage Temperature
-30 to +70 ºC
Specifications Operating Temperature Range
-20 to +70 ºC
Specifications Operating Voltage Range
20.4 to 27.6 V
Specifications Rated Current
0.16 A
Specifications Rated Input Power
3.84 W
Specifications Rated Speed
1900 rpm
Specifications Rated Voltage
24 V
Specifications Sensor Lead Wire Color
Yellow
Specifications Sound Pressure Level
38 dBA
