San Ace 140W Splash Proof Fan, 140x140x38mm, 48V
San Ace 140W Splash Proof Fan, 140x140x38mm, 48V
SKU:SAN-8c4002
High-quality San Ace 140W Splash Proof Fan, 48V, 1900 rpm, aluminum frame, ideal for challenging environments.
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Initiate Order
San Ace 140W Splash Proof Fan, 140x140x38mm, 48V
$29.99
Quantity: 1
Claim Your Seller Account
San Ace 140W Splash Proof Fan, 140x140x38mm, 48V
$29.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The San Ace 140W Series Splash Proof Fan is a high-quality fan designed for reliable performance in challenging environments. With dimensions of 140 x 140 x 38 mm, this fan features an aluminum frame and UL94V-1 rated plastic impeller for enhanced safety. Operating at a rated voltage of 48V and a speed of 1900 rpm, it delivers a maximum airflow of 3.30 m³/min with a maximum static pressure of 52 Pa. Additionally, it meets industry standards for sound pressure levels, ensuring quiet operation. Ideal for both consumer and institutional use, this fan offers durability, efficiency, and compliance with relevant standards for long-term reliability.
Product Specifications
Specifications Anode Lead Wire Color
Red
Specifications Cathode Lead Wire Color
Black | Blue
Specifications Dimensions
140 x 140 x 38 mm
Specifications Expected Life At 60c
100000 hours
Specifications Frame Material
Aluminum
Specifications Impeller Material
Plastics (Flammability: UL94V-1)
Specifications Mass
650 g
Specifications Maximum Air Flow
3.30 m³/min | 117 ft³/min
Specifications Maximum Static Pressure
52 Pa | 0.209 inH2O
Specifications Non Condensing Storage Temperature
-30 to +70 ºC
Specifications Operating Temperature Range
-20 to +70 ºC
Specifications Operating Voltage Range
40.8 to 55.2 V
Specifications Rated Current
0.09 A
Specifications Rated Input Power
4.32 W
Specifications Rated Speed
1900 rpm
Specifications Rated Voltage
48 V
Specifications Sensor Lead Wire Color
Yellow
Specifications Sound Pressure Level
38 dBA
