San Ace 140W Splash Proof Fan, 140x140x38mm, 48V DC, 2600rpm
San Ace 140W Splash Proof Fan, 140x140x38mm, 48V DC, 2600rpm
SKU:SAN-20796e
High-performance San Ace 140W Series Splash Proof Fan ideal for reliable cooling in various applications.
Regular price
$49.99
Regular price
Sale price
$49.99
Unit price
per
Initiate Order
San Ace 140W Splash Proof Fan, 140x140x38mm, 48V DC, 2600rpm
$49.99
Quantity: 1
Claim Your Seller Account
San Ace 140W Splash Proof Fan, 140x140x38mm, 48V DC, 2600rpm
$49.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The San Ace 140W Series Splash Proof Fan is a high-performance cooling solution designed with durability and efficiency in mind. With a sturdy aluminum frame, UL94V-1 rated plastic impeller, and rated voltage of 48V, this fan delivers a reliable airflow of 4.6 m³/min while operating quietly at 46 dBA. It meets stringent industrial standards for reliability and performance, making it ideal for both consumer and institutional applications.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Specifications Anode Lead Wire Color
Red
Specifications Cathode Lead Wire Color
Black | Blue
Specifications Dimensions
140 x 140 x 38 mm
Specifications Expected Life At 60c
100000 hours
Specifications Frame Material
Aluminum
Specifications Impeller Material
Plastics (Flammability: UL94V-1)
Specifications Mass
650 g
Specifications Maximum Air Flow
4.6 m³/min | 159 ft³/min
Specifications Maximum Static Pressure
98 Pa | 0.394 inH2O
Specifications Non Condensing Storage Temperature
-30 to +70 ºC
Specifications Operating Temperature Range
-20 to +70 ºC
Specifications Operating Voltage Range
40.8 to 55.2 V
Specifications Rated Current
0.2 A
Specifications Rated Input Power
9.6 W
Specifications Rated Speed
2600 rpm
Specifications Rated Voltage
48 V
Specifications Sensor Lead Wire Color
Yellow
Specifications Sound Pressure Level
46 dBA
