San Ace 140W Splash Proof Fan - 140x140x51mm, 24V, 5.9 m³/min
San Ace 140W Splash Proof Fan - 140x140x51mm, 24V, 5.9 m³/min
SKU:SAN-576ca3
San Ace 140W Splash Proof Fan - Efficient cooling for industrial needs.
Regular price
$49.99
Regular price
Sale price
$49.99
Unit price
per
Initiate Order
San Ace 140W Splash Proof Fan - 140x140x51mm, 24V, 5.9 m³/min
$49.99
Quantity: 1
Claim Your Seller Account
San Ace 140W Splash Proof Fan - 140x140x51mm, 24V, 5.9 m³/min
$49.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The San Ace 140W Series Splash Proof Fan is a durable and efficient cooling solution designed for industrial and institutional settings. With dimensions of 140 x 140 x 51 mm, this fan features an aluminum frame and plastic impeller with UL94V-1 flammability rating. Operating at a rated voltage of 24V and a speed of 3,100 rpm, it delivers a maximum air flow of 5.9 m³/min while maintaining a sound pressure level of 49 dBA. Built to last with an expected lifespan of 100,000 hours at 60°C, this fan ensures reliable performance in demanding environments.
Product Specifications
Specifications Anode Lead Wire Color
Red
Specifications Cathode Lead Wire Color
Black | Blue
Specifications Dimensions
140 x 140 x 51 mm
Specifications Expected Life At 60c
100000 hours
Specifications Frame Material
Aluminum
Specifications Impeller Material
Plastics (Flammability: UL94V-1)
Specifications Mass
700 g
Specifications Maximum Air Flow
5.9 m³/min | 208.5 ft³/min
Specifications Maximum Static Pressure
130 Pa | 0.52 inH2O
Specifications Non Condensing Storage Temperature
-30 to +70 ºC
Specifications Operating Temperature Range
-20 to +70 ºC
Specifications Operating Voltage Range
20.4 to 27.6 V
Specifications Rated Current
0.6 A
Specifications Rated Input Power
14.4 W
Specifications Rated Speed
3,100 rpm
Specifications Rated Voltage
24 V
Specifications Sensor Lead Wire Color
Yellow
Specifications Sound Pressure Level
49 dBA
