San Ace 172W Splash Proof Fan 24V, 4100 RPM

Name: San Ace 172W Splash Proof Fan 24V, 4100 RPM
Brand: Marsh Electronics, Inc.
SKU: SAN-07a2b8
Price: 79.99 USD
Availability: OutOfStock

SKU:SAN-07a2b8

Powerful San Ace 172W Series Splash Proof Fan for industrial cooling needs.

$79.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The San Ace 172W Splash Proof Fan is a reliable cooling solution designed for industrial applications. With dimensions of 172 x 150 x 51 mm and a sturdy aluminum frame, this fan ensures efficient heat dissipation. The UL94V-1 compliant plastic impeller guarantees safety. Operating at 24V with a rated current of 1.3 A, it delivers a powerful airflow of 8.5 m³/min and a static pressure of 243 Pa. With a noise level of 60 dBA, this fan is suitable for various environments and has an expected life of 40,000 hours at 60°C.

Product Specifications

Specifications Air Flow

8.5 mÂ³/min | 300 ftÂ³/min

Specifications Anode Lead Wire Color

Red

Specifications Cathode Lead Wire Color

Black | Blue

Specifications Dimensions

172 x 150 x 51 mm

Specifications Expected Life At 60c

40,000 hours

Specifications Frame Material

Aluminum

Specifications Impeller Material

Plastics (Flammability: UL94V-1)

Specifications Mass

860 g

Specifications Non Condensing Storage Temperature

-30 to +70 ÂºC

Specifications Operating Temperature Range

-20 to 60 ÂºC

Specifications Operating Voltage Range

20.4 to 27.6 V

Specifications Rated Current

1.3 A

Specifications Rated Input Power

31.2 W

Specifications Rated Speed

4100 rpm

Specifications Rated Voltage

24 V

Specifications Sensor Lead Wire Color

Yellow

Specifications Sound Pressure Level

60 dBA

Specifications Static Pressure

243 Pa | 0.976 inH2O
