San Ace 60W Splash Proof Fan, 24V, 60x60x25 mm

Name: San Ace 60W Splash Proof Fan, 24V, 60x60x25 mm
Brand: Marsh Electronics, Inc.
SKU: SAN-e21093
Price: 29.99 USD
Availability: OutOfStock

SKU:SAN-e21093

High-performance 24V 60x60x25 mm splash-proof fan designed for reliability in challenging environments.

$29.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The 9WP0624G401 from the San Ace 60W Series is a high-performance splash-proof fan designed for reliable cooling in challenging environments. Its UL94V-0 and UL94V-1 flammability-rated plastics ensure safety. With a rated voltage of 24V and operating voltage range of 20.4-27.6V, this fan delivers a maximum air flow of 0.78 m³/min and maximum static pressure of 87.3 Pa. It operates between -20 to +60 ºC with an expected life of 40,000 hours at 60ºC. Weighing 110g, this fan is compact at 60x60x25 mm, making it ideal for a variety of applications.

Product Specifications

Specifications Anode Lead Wire Color

Red

Specifications Cathode Lead Wire Color

Black

Specifications Dimensions

60Ã60Ã25 mm

Specifications Expected Life At 60c

40,000 hours

Specifications Frame Material

Plastics (Flammability: UL94V-0)

Specifications Impeller Material

Plastics (Flammability: UL94V-1)

Specifications Mass

110 g

Specifications Maximum Air Flow

0.78 mÂ³/min | 27.5 ftÂ³/min

Specifications Maximum Static Pressure

87.3 Pa | 0.351 inH2O

Specifications Non Condensing Storage Temperature

-30 to +70 ÂºC

Specifications Operating Temperature

-20 to +60 ÂºC

Specifications Operating Voltage Range

20.4 to 27.6 V

Specifications Rated Current

0.13 A

Specifications Rated Input Power

3.12 W

Specifications Rated Speed

5,600 rpm

Specifications Rated Voltage

24 V

Specifications Sensor Lead Wire Color

Yellow

Specifications Sound Pressure Level

39 dBA

San Ace 60W Splash Proof Fan, 24V, 60x60x25 mm
