San Ace 80 Series AC Fan - 109S051, 80x80x25mm
San Ace 80 Series AC Fan - 109S051, 80x80x25mm
SKU:SAN-c6065b
High-performance San Ace AC Fan - 109S051, perfect for reliable cooling in various setups.
Regular price
$32.99
Regular price
Sale price
$32.99
Unit price
per
Initiate Order
San Ace 80 Series AC Fan - 109S051, 80x80x25mm
$32.99
Quantity: 1
Claim Your Seller Account
San Ace 80 Series AC Fan - 109S051, 80x80x25mm
$32.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The San Ace 80 Series AC Fan - 109S051 is a high-quality cooling solution designed for efficient performance in both consumer and institutional settings. With an aluminum frame and UL94V-1 rated plastics impeller, this fan ensures durability and safety. Operating at a rated voltage of 200V and delivering a maximum airflow of 0.76 m³/min, it meets stringent industry standards for reliability and performance. With a sound pressure level of 33 dBA and an expected life of 25,000 hours at 60°C, this fan is ideal for applications requiring quiet operation and long-term usage.
Product Specifications
Specifications Current
0.06/0.05 A
Specifications Dielectric Strength
50/60Hz 1,500VAC 1minute (between lead conductor and frame)
Specifications Dimensions
80Ã80Ã25 mm
Specifications Expected Life At 60c
25000 hours
Specifications Frame Material
Aluminum
Specifications Frequency
50/60 Hz
Specifications Impeller Material
Plastics (Flammability: UL94V-1)
Specifications Input
9/7 W
Specifications Locked Rotor Current
0.06/0.05 A
Specifications Mass
270 g
Specifications Maximum Air Flow
0.63/0.76 m³/min | 22.3/26.9 ft³/min
Specifications Maximum Static Pressure
27.5/38.3 Pa | 0.110/0.154 inH2O
Specifications Non Condensing Storage Temperature
-30 to +70 ºC
Specifications Operating Temperature
-30 to +60 ºC
Specifications Operating Voltage Range
Voltage of each model ±10%
Specifications Rated Speed
2,650/3,100 rpm
Specifications Rated Voltage
200 V
Specifications Sound Pressure Level
30/33 dBA
