San Ace 92 Series AC Fan - 92Ã92Ã25mm, 230V, 50/60Hz
San Ace 92 Series AC Fan - 92Ã92Ã25mm, 230V, 50/60Hz
SKU:SAN-bc758a
Efficient and durable San Ace 92 Series AC Fan - ideal for consumer and institutional cooling needs.
Regular price
$34.99
Regular price
Sale price
$34.99
Unit price
per
Initiate Order
San Ace 92 Series AC Fan - 92Ã92Ã25mm, 230V, 50/60Hz
$34.99
Quantity: 1
Claim Your Seller Account
San Ace 92 Series AC Fan - 92Ã92Ã25mm, 230V, 50/60Hz
$34.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The 109S194 San Ace 92 Series AC Fan is a reliable cooling solution, featuring aluminum frame and UL94V-1 rated plastics. With a dielectric strength of 1,500VAC, this fan ensures safety and efficiency. Operating at 1500/1700 RPM, it delivers a maximum air flow of 0.55/0.65 m³/min. Designed for durability, it has an expected life of 25,000 hours at 60ºC. Ideal for both consumer and institutional use, this fan meets rigorous procurement standards and offers superior performance.
Product Specifications
Specifications Current
0.05/0.04 A
Specifications Dielectric Strength
50/60Hz 1,500VAC 1minute (between input terminal and frame)
Specifications Dielectric Strength With Sensor Between Ac Input
50/60 Hz 1,500 VAC 1 minute
Specifications Dielectric Strength With Sensor Between G And Dc
50/60Hz 1,000VAC 1minute
Specifications Dimensions
92Ã92Ã25 mm
Specifications Expected Life At 60c
25000 hours
Specifications Frame Material
Aluminum
Specifications Frequency
50/60 Hz
Specifications Impeller Material
Plastics (Flammability: UL94V-1)
Specifications Input
8/7 W
Specifications Locked Rotor Current
0.05/0.04 A
Specifications Mass
290 g
Specifications Maximum Air Flow
0.55/0.65 m³/min | 19.4/23 ft³/min
Specifications Maximum Static Pressure
12.5/16.3 Pa | 0.050/0.065 inH2O
Specifications Non Condensing Storage Temperature
-30 to +70 ºC
Specifications Operating Temperature
-30 to +60 ºC
Specifications Operating Voltage Range
Voltage of each model ±10%
Specifications Rated Speed
1500/1700
Specifications Rated Voltage
230 V
Specifications Sensor Purpose Anode Lead Wire Color
Brown
Specifications Sensor Purpose Cathode Lead Wire Color
Black
Specifications Sensor Purpose Lead Wire Color
Yellow
Specifications Sound Pressure Level
24/27 dBA
