San Ace 92 Series AC Fan - Model 109S091
San Ace 92 Series AC Fan - Model 109S091
SKU:SAN-e8a42d
Enhance cooling efficiency with the San Ace 92 Series AC Fan. Durable construction, high airflow, and long lifespan for reliable performance.
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Initiate Order
San Ace 92 Series AC Fan - Model 109S091
$29.99
Quantity: 1
Claim Your Seller Account
San Ace 92 Series AC Fan - Model 109S091
$29.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Upgrade your cooling system with the San Ace 92 Series AC Fan - Model 109S091. This industrial-grade fan features a durable aluminum frame and UL94V-1 rated plastic impeller. With a dielectric strength of up to 1,500VAC, it ensures reliable performance. Operating at a maximum speed of 3,100 RPM, it delivers an airflow of up to 1.1 m³/min. The fan meets stringent institutional procurement standards and is designed for longevity, offering an expected life of 25,000 hours at 60°C.
Product Specifications
Specifications Current
0.1 /0.09 A
Specifications Dielectric Strength
50/60Hz 1,500VAC 1minute (between input terminal and frame)
Specifications Dielectric Strength With Sensor Between Ac Input
50/60 Hz 1,500 VAC 1 minute
Specifications Dielectric Strength With Sensor Between G And Dc
50/60Hz 1,000VAC 1minute
Specifications Dimensions
92Ã92Ã25 mm
Specifications Expected Life At 60c
25000 hours
Specifications Frame Material
Aluminum
Specifications Frequency
50/60 Hz
Specifications Impeller Material
Plastics (Flammability: UL94V-1)
Specifications Input
8/7 W
Specifications Locked Rotor Current
0.13/0.12 A
Specifications Mass
290 g
Specifications Maximum Air Flow
0.95/1.1 m³/min | 33.6/38.9 ft³/min
Specifications Maximum Static Pressure
39.2/49.0 Pa | 0.157/0.197 inH2O
Specifications Non Condensing Storage Temperature
-30 to +70 ºC
Specifications Operating Temperature
-30 to +60 ºC
Specifications Operating Voltage Range
Voltage of each model ±10%
Specifications Rated Speed
2,700/3,100
Specifications Rated Voltage
100 V
Specifications Sensor Purpose Anode Lead Wire Color
Brown
Specifications Sensor Purpose Cathode Lead Wire Color
Black
Specifications Sensor Purpose Lead Wire Color
Yellow
Specifications Sound Pressure Level
35/38 dBA
