San Ace 92 Series AC Fan - Model 109S094
San Ace 92 Series AC Fan - Model 109S094
SKU:SAN-0f712b
High-performance San Ace 92 Series AC Fan - Model 109S094, ideal for industrial and institutional cooling applications.
Regular price
$49.99
Regular price
Sale price
$49.99
Unit price
per
Initiate Order
San Ace 92 Series AC Fan - Model 109S094
$49.99
Quantity: 1
Claim Your Seller Account
San Ace 92 Series AC Fan - Model 109S094
$49.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The San Ace 92 Series AC Fan - Model 109S094 is a high-performance cooling solution designed for industrial and institutional applications. With a lightweight aluminum frame and UL94V-1 rated plastics impeller, this fan ensures reliable cooling while meeting stringent safety standards. Operating at 230V and featuring a dielectric strength of up to 1,500VAC, it offers efficient airflow of up to 1.1 m³/min with a low sound pressure level of 38 dBA. Built to last with an expected lifespan of 25,000 hours at 60ºC, this fan is ideal for demanding environments requiring durable and compliant cooling solutions.
Product Specifications
Specifications Current
0.06/0.05 A
Specifications Dielectric Strength
50/60Hz 1,500VAC 1minute (between input terminal and frame)
Specifications Dielectric Strength With Sensor Between Ac Input
50/60 Hz 1,500 VAC 1 minute
Specifications Dielectric Strength With Sensor Between G And Dc
50/60Hz 1,000VAC 1minute
Specifications Dimensions
92Ã92Ã25 mm
Specifications Expected Life At 60c
25000 hours
Specifications Frame Material
Aluminum
Specifications Frequency
50/60 Hz
Specifications Impeller Material
Plastics (Flammability: UL94V-1)
Specifications Input
10/9 W
Specifications Locked Rotor Current
0.07/0.07 A
Specifications Mass
290 g
Specifications Maximum Air Flow
0.95/1.1 m³/min | 33.6/38.9 ft³/min
Specifications Maximum Static Pressure
39.2/49.0 Pa | 0.157/0.197 inH2O
Specifications Non Condensing Storage Temperature
-30 to +70 ºC
Specifications Operating Temperature
-30 to +60 ºC
Specifications Operating Voltage Range
Voltage of each model ±10%
Specifications Rated Speed
2,700/3,100
Specifications Rated Voltage
230 V
Specifications Sensor Purpose Anode Lead Wire Color
Brown
Specifications Sensor Purpose Cathode Lead Wire Color
Black
Specifications Sensor Purpose Lead Wire Color
Yellow
Specifications Sound Pressure Level
35/38 dBA
