San Ace 92W Splash Proof Fan
San Ace 92W Splash Proof Fan
SKU:SAN-9dc281
High-performance San Ace 92W Splash Proof Fan for reliable cooling in challenging conditions. Meet various standards and operates at 24 V.
Regular price
$49.99
Regular price
Sale price
$49.99
Unit price
per
Initiate Order
San Ace 92W Splash Proof Fan
$49.99
Quantity: 1
Claim Your Seller Account
San Ace 92W Splash Proof Fan
$49.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The San Ace 92W Splash Proof Fan is designed for reliable performance in demanding environments. With dimensions of 92 x 92 x 38 mm and a robust plastic frame, this fan ensures durability and safety. Operating at a rated voltage of 24 V and meeting a range of specifications including UL94V-0 flammability rating, PWM control features, and a long expected life of 300,000 hours, this fan is ideal for both consumer and institutional applications.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Specifications Anode Lead Wire Color
Red
Specifications Cathode Lead Wire Color
Black
Specifications Control Lead Wire Color
Brown
Specifications Dimensions
92 x 92 x 38 mm
Specifications Expected Life At 60c
300000 hours
Specifications Frame Material
Plastics (Flammability: UL94V-0)
Specifications Impeller Material
Plastics (Flammability: UL94V-1)
Specifications Mass
265 g
Specifications Maximum Air Flow
5.05 m³/min | 178 ft³/min
Specifications Maximum Pulse Width Modulation Pwm Duty Cycle
100 %
Specifications Maximum Rated Current
1.6 A
Specifications Maximum Rated Input Power
38.4 W
Specifications Maximum Rated Speed
8500 rpm
Specifications Maximum Sound Pressure Level
64 dBA
Specifications Maximum Static Pressure
385 Pa | 1.55 inH2O
Specifications Minimum Air Flow
1.78 m³/min | 62.9 ft³/min
Specifications Minimum Pulse Width Modulation Pwm Duty Cycle
20 %
Specifications Minimum Rated Current
0.16 A
Specifications Minimum Rated Input Power
3.84 W
Specifications Minimum Rated Speed
3000 rpm
Specifications Minimum Sound Pressure Level
38 dBA
Specifications Minimum Static Pressure
47.9 Pa | 0.19 inH2O
Specifications Non Condensing Storage Temperature
-30 to +70 ºC
Specifications Operating Temperature Range
-20 to 60 ºC
Specifications Operating Voltage Range
20.4 to 26.4 V
Specifications Pulse Width Modulation Pwm Frequency
25 kHz
Specifications Rated Voltage
24 V
Specifications Sensor Lead Wire Color
Yellow
