San Ace 92W Splash Proof Fan
San Ace 92W Splash Proof Fan
SKU:SAN-0fb9c3
Reliable San Ace 92W Splash Proof Fan for efficient and quiet cooling in demanding environments.
Regular price
$24.99
Regular price
Sale price
$24.99
Unit price
per
Initiate Order
San Ace 92W Splash Proof Fan
$24.99
Quantity: 1
Claim Your Seller Account
San Ace 92W Splash Proof Fan
$24.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The San Ace 92W Splash Proof Fan is a reliable cooling solution designed for demanding environments. With a compact size of 92 x 92 x 25 mm and a durable frame and impeller made of UL94V-0 rated plastics, this fan ensures both performance and safety. Operating at a rated voltage of 12V and a speed of 2650 rpm, it delivers an air flow of 1.24 m³/min and a static pressure of 32.2 Pa. With a sound pressure level of 30 dBA and an expected life of 40,000 hours at 60ºC, this fan offers sustained cooling with minimal noise and maintenance requirements.
Product Specifications
Specifications Air Flow
1.24 m³/min | 43.8 ft³/min
Specifications Anode Lead Wire Color
Red
Specifications Cathode Lead Wire Color
Black | Blue
Specifications Dimensions
92 x 92 x 25 mm
Specifications Expected Life At 60c
40,000 hours
Specifications Frame Material
Plastics (Flammability: UL94V-0)
Specifications Impeller Material
Plastics (Flammability: UL94V-0)
Specifications Mass
120 g
Specifications Non Condensing Storage Temperature
-30 to +70 ºC
Specifications Operating Temperature Range
-20 to +70 ºC
Specifications Operating Voltage Range
6 to 13.8 V
Specifications Rated Current
0.14 A
Specifications Rated Input Power
1.68 W
Specifications Rated Speed
2650 rpm
Specifications Rated Voltage
12 V
Specifications Sensor Lead Wire Color
Yellow
Specifications Sound Pressure Level
30 dBA
Specifications Static Pressure
32.2 Pa | 0.129 inH2O
