San Ace 92WS Splash Proof Fan
San Ace 92WS Splash Proof Fan
SKU:SAN-7da050
Reliable San Ace 92WS Splash Proof Fan with high air flow, low noise, and long-lasting performance. Perfect for institutional cooling needs.
Regular price
$25.99
Regular price
Sale price
$25.99
Unit price
per
Initiate Order
San Ace 92WS Splash Proof Fan
$25.99
Quantity: 1
Claim Your Seller Account
San Ace 92WS Splash Proof Fan
$25.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The San Ace 92WS Splash Proof Fan is a reliable cooling solution suitable for both consumer and institutional use. With dimensions of 92 x 92 x 25 mm and a maximum air flow of 1.01 m³/min, this fan is designed to meet high standards of performance and durability. Made from UL94V-0 and UL94V-1 plastics, it ensures safety and quality. Operating at a rated voltage of 24V and a sound pressure level of 27 dBA, this fan offers efficient cooling with minimal noise. With an expected life of 40,000 hours at 60ºC, it is a cost-effective and long-lasting choice for various applications.
Product Specifications
Specifications Anode Lead Wire Color
Red
Specifications Cathode Lead Wire Color
Black | Blue
Specifications Dimensions
92 x 92 x 25 mm
Specifications Expected Life At 60c
40,000 hours
Specifications Frame Material
Plastics (Flammability: UL94V-0)
Specifications Impeller Material
Plastics (Flammability: UL94V-1)
Specifications Mass
150 g
Specifications Maximum Air Flow
1.01 m³/min | 35.7 ft³/min
Specifications Maximum Static Pressure
23.5 Pa | 0.094 inH2O
Specifications Non Condensing Storage Temperature
-30 to +70 ºC
Specifications Operating Temperature Range
-20 to +70 ºC
Specifications Operating Voltage Range
20.4 to 27.6 V
Specifications Rated Current
0.06 A
Specifications Rated Input Power
1.44 W
Specifications Rated Speed
2100 rpm
Specifications Rated Voltage
24 V
Specifications Sensor Lead Wire Color
Yellow
Specifications Sound Pressure Level
27 dBA
