San Ace 92WS Splash Proof Fan, 24V DC, 92x92x25mm

Name: San Ace 92WS Splash Proof Fan, 24V DC, 92x92x25mm
Brand: Marsh Electronics, Inc.
SKU: SAN-27e6e2
Price: 29.99 USD
Availability: OutOfStock

SKU:SAN-27e6e2

Reliable San Ace 92WS Splash Proof Fan, 24V, 92x92x25mm. Optimal airflow, durable design, and low noise operation.

$29.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The San Ace 92WS Splash Proof Fan is a reliable cooling solution built for durability and performance. With dimensions of 92 x 92 x 25 mm and a rated voltage of 24V, this fan delivers a maximum airflow of 1.38 m³/min. It features a UL94V-0 plastic frame and UL94V-1 plastic impeller for enhanced safety. Operating within a wide temperature range of -20 to +70 ºC, this fan offers a rated speed of 2850 rpm and an expected life of 40,000 hours at 60ºC. Trust in its 45.1 Pa static pressure and low 33 dBA sound level for efficient and quiet cooling.

Product Specifications

Specifications Anode Lead Wire Color

Red

Specifications Cathode Lead Wire Color

Black | Blue

Specifications Dimensions

92 x 92 x 25 mm

Specifications Expected Life At 60c

40,000 hours

Specifications Frame Material

Plastics (Flammability: UL94V-0)

Specifications Impeller Material

Plastics (Flammability: UL94V-1)

Specifications Mass

150 g

Specifications Maximum Air Flow

1.38 mÂ³/min | 48.7 ftÂ³/min

Specifications Maximum Static Pressure

45.1 Pa | 0.181 inH2O

Specifications Non Condensing Storage Temperature

-30 to +70 ÂºC

Specifications Operating Temperature Range

-20 to +70 ÂºC

Specifications Operating Voltage Range

20.4 to 27.6 V

Specifications Rated Current

0.1 A

Specifications Rated Input Power

2.4 W

Specifications Rated Speed

2850 rpm

Specifications Rated Voltage

24 V

Specifications Sensor Lead Wire Color

Yellow

Specifications Sound Pressure Level

33 dBA
