San Ace 92WS Splash Proof Fan, 92 x 92 x 25 mm, 24V
San Ace 92WS Splash Proof Fan, 92 x 92 x 25 mm, 24V
SKU:SAN-c91736
Explore the San Ace 92WS Splash Proof Fan for efficient cooling in demanding environments. Rated at 24V with a maximum air flow of 1.18 m³/min.
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Initiate Order
San Ace 92WS Splash Proof Fan, 92 x 92 x 25 mm, 24V
$29.99
Quantity: 1
Claim Your Seller Account
San Ace 92WS Splash Proof Fan, 92 x 92 x 25 mm, 24V
$29.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The San Ace 92WS Splash Proof Fan is a reliable cooling solution designed for optimal performance in demanding environments. With a sturdy plastic frame and UL94V-0 flammability rating, this fan ensures safety without compromising efficiency. Operating within a wide temperature range of -20 to +70 °C, this fan delivers a maximum air flow of 1.18 m³/min at a rated speed of 2450 rpm. Meeting industry standards for sound pressure levels and static pressure, this fan is built to last, with an expected life of 40,000 hours at 60°C.
Product Specifications
Specifications Anode Lead Wire Color
Red
Specifications Cathode Lead Wire Color
Black | Blue
Specifications Dimensions
92 x 92 x 25 mm
Specifications Expected Life At 60c
40,000 hours
Specifications Frame Material
Plastics (Flammability: UL94V-0)
Specifications Impeller Material
Plastics (Flammability: UL94V-1)
Specifications Mass
150 g
Specifications Maximum Air Flow
1.18 m³/min | 41.7 ft³/min
Specifications Maximum Static Pressure
32.3 Pa | 0.130 inH2O
Specifications Non Condensing Storage Temperature
-30 to +70 ºC
Specifications Operating Temperature Range
-20 to +70 ºC
Specifications Operating Voltage Range
20.4 to 27.6 V
Specifications Rated Current
0.07 A
Specifications Rated Input Power
1.68 W
Specifications Rated Speed
2450 rpm
Specifications Rated Voltage
24 V
Specifications Sensor Lead Wire Color
Yellow
Specifications Sound Pressure Level
30 dBA
