San Ace 92WS Splash Proof Fan - 92 x 92 x 25 mm, 24V
San Ace 92WS Splash Proof Fan - 92 x 92 x 25 mm, 24V
SKU:SAN-ec9dfe
Reliable San Ace 92WS Splash Proof Fan - Ideal for industrial use, 92 x 92 x 25 mm, 24V
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Initiate Order
San Ace 92WS Splash Proof Fan - 92 x 92 x 25 mm, 24V
$29.99
Quantity: 1
Claim Your Seller Account
San Ace 92WS Splash Proof Fan - 92 x 92 x 25 mm, 24V
$29.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The San Ace 92WS Splash Proof Fan is a reliable cooling solution, ideal for industrial and institutional settings. With dimensions of 92 x 92 x 25 mm and a rated voltage of 24V, this fan delivers maximum air flow of 0.8 m³/min. Constructed with UL94V-0 and UL94V-1 flammability-rated plastics, it ensures safety and durability. Operating temperature range of -20 to +70 ºC and an expected life of 40,000 hours at 60ºC make it a long-lasting and efficient choice for various applications.
Product Specifications
Specifications Anode Lead Wire Color
Red
Specifications Cathode Lead Wire Color
Black | Blue
Specifications Dimensions
92 x 92 x 25 mm
Specifications Expected Life At 60c
40,000 hours
Specifications Frame Material
Plastics (Flammability: UL94V-0)
Specifications Impeller Material
Plastics (Flammability: UL94V-1)
Specifications Mass
150 g
Specifications Maximum Air Flow
0.8 m³/min | 28.2 ft³/min
Specifications Maximum Static Pressure
16.7 Pa | 0.067 inH2O
Specifications Non Condensing Storage Temperature
-30 to +70 ºC
Specifications Operating Temperature Range
-20 to +70 ºC
Specifications Operating Voltage Range
20.4 to 27.6 V
Specifications Rated Current
0.05 A
Specifications Rated Input Power
1.2 W
Specifications Rated Speed
1700 rpm
Specifications Rated Voltage
24 V
Specifications Sensor Lead Wire Color
Yellow
Specifications Sound Pressure Level
23 dBA
