Sandpiper S05 Metallic Ball Valve Diaphragm Pump
Sandpiper S05 Metallic Ball Valve Diaphragm Pump
SKU:PRO-07574a
Reliable Sandpiper S05 Metallic Ball Valve Diaphragm Pump for standard duty tasks. Max flow rate of 15 gpm, ball check valve type, and durable UniRupp® PTFE/PTFE elastomers.
Regular price
$879.99
Regular price
Sale price
$879.99
Unit price
per
Initiate Order
Sandpiper S05 Metallic Ball Valve Diaphragm Pump
$879.99
Quantity: 1
Claim Your Seller Account
Sandpiper S05 Metallic Ball Valve Diaphragm Pump
$879.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Sandpiper S05 Metallic Ball Valve Diaphragm Pump is a reliable air-powered double diaphragm pump designed for standard duty applications. With a max flow rate of 15 gpm and a solids handling capacity of 0.125 inches, this pump features a ball check valve type and UniRupp® PTFE/PTFE elastomers for enhanced durability. The aluminum wetted materials ensure compatibility with various fluids, making it ideal for waste water handling. Trust in the Sandpiper S05 for efficient and robust pumping performance in water, wastewater, sump, and utility applications.
Product Specifications
Specifications Check Valve Seat
PTFE
Specifications Check Valve Type
Ball
Specifications Design Level
1
Specifications Discharge Pipe Size Internal
1/2" BSPT | 1/2" NPT
Specifications Displacement Per Stroke
0.026 gal | 0.098 lit
Specifications Elastomers
UniRupp® PTFE/PTFE
Specifications Intake Pipe Size Internal
1/2" BSPT | 1/2" NPT
Specifications Max Flow Rate
0 - 15 gpm | 0 - 56 lpm
Specifications Non Wetted Material
Aluminum
Specifications Porting Position
NPT Threads
Specifications Pump Style
Standard
Specifications Solids Handling
0.125 in | 3 mm
Specifications Type
Air Powered Double Diaphragm Pump | Pumps - Air Operated Diaphragm | Pumps - AOD - Ball Valve - Top Ported | Pumps - Sandpiper Standard Duty
Specifications Weight
15 lbs | 7 kg
Specifications Wetted Moc
Aluminum
Category 6
Standard Duty Diaphragm Pumps
