Sandpiper S05 Metallic Ball Valve Diaphragm Pump

Name: Sandpiper S05 Metallic Ball Valve Diaphragm Pump
Brand: Springer Pumps, LLC
SKU: PRO-f201e9
Price: 799.99 USD
Availability: OutOfStock

SKU:PRO-f201e9

Durable and reliable, the Sandpiper S05 Diaphragm Pump is ideal for waste water handling with ball valve technology.

$799.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The Sandpiper S05 Metallic Ball Valve Diaphragm Pump is a robust air-powered double diaphragm pump designed for standard duty applications in waste water handling. With a compact design and aluminum construction, this pump offers durability and reliability. It features a 1/2" intake and discharge pipe size, a ball check valve type, and can handle solids up to 0.125 inches. The pump's EPDM/EPDM elastomers ensure compatibility with various fluids, making it suitable for industrial and institutional use.

Product Specifications

Specifications Check Valve Seat

UHMW Polyethylene

Specifications Check Valve Type

Ball

Specifications Design Level

Specifications Discharge Pipe Size Internal

1/2" BSPT | 1/2" NPT

Specifications Displacement Per Stroke

0.026 gal | 0.098 lit

Specifications Elastomers

EPDM/EPDM

Specifications Intake Pipe Size Internal

1/2" BSPT | 1/2" NPT

Specifications Max Flow Rate

0 - 15 gpm | 0 - 56 lpm

Specifications Non Wetted Material

Aluminum

Specifications Porting Position

NPT Threads

Specifications Pump Style

Standard

Specifications Solids Handling

0.125 in | 3 mm

Specifications Type

Air Powered Double Diaphragm Pump | Pumps - Air Operated Diaphragm | Pumps - AOD - Ball Valve - Top Ported | Pumps - Sandpiper Standard Duty

Specifications Weight

15 lbs | 7 kg

Specifications Wetted Moc

Aluminum
