Sandpiper S05 Metallic Ball Valve Diaphragm Pump
Sandpiper S05 Metallic Ball Valve Diaphragm Pump
SKU:PRO-063401
High-performance S05 Metallic Ball Valve Diaphragm Pump with 15 gpm flow rate, perfect for water and wastewater applications.
Regular price
$499.99
Regular price
Sale price
$499.99
Unit price
per
Initiate Order
Sandpiper S05 Metallic Ball Valve Diaphragm Pump
$499.99
Quantity: 1
Claim Your Seller Account
Sandpiper S05 Metallic Ball Valve Diaphragm Pump
$499.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Sandpiper S05 Metallic Ball Valve Diaphragm Pump is a top-performing air-operated double diaphragm pump designed for standard duty applications. With a durable aluminum construction and Viton/PTFE elastomers, it boasts a 0.125-inch solids handling capability and a maximum flow rate of 15 gpm. The pump's ball check valve, PTFE check valve seat, and NPT porting position ensure reliability and efficiency in pumping operations. Ideal for water, wastewater, sump, and utility applications.
Product Specifications
Specifications Check Valve Seat
PTFE
Specifications Check Valve Type
Ball
Specifications Design Level
1
Specifications Discharge Pipe Size Internal
1/2" BSPT | 1/2" NPT
Specifications Displacement Per Stroke
0.026 gal | 0.098 lit
Specifications Elastomers
Viton®/PTFE
Specifications Intake Pipe Size Internal
1/2" BSPT | 1/2" NPT
Specifications Max Flow Rate
0 - 15 gpm | 0 - 56 lpm
Specifications Non Wetted Material
Aluminum
Specifications Porting Position
NPT Threads
Specifications Pump Style
Standard
Specifications Solids Handling
0.125 in | 3 mm
Specifications Type
Air Powered Double Diaphragm Pump | Pumps - Air Operated Diaphragm | Pumps - AOD - Ball Valve - Top Ported | Pumps - Sandpiper Standard Duty
Specifications Weight
15 lbs | 7 kg
Specifications Wetted Moc
Aluminum
Category 6
Standard Duty Diaphragm Pumps
