Sandpiper S07 Non-Metallic Ball Valve Diaphragm Pump
Sandpiper S07 Non-Metallic Ball Valve Diaphragm Pump
SKU:PRO-8b9035
Reliable Sandpiper S07 Non-Metallic Diaphragm Pump for institutional wastewater applications.
Regular price
$1,599.99
Regular price
Sale price
$1,599.99
Unit price
per
Initiate Order
Sandpiper S07 Non-Metallic Ball Valve Diaphragm Pump
$1,599.99
Quantity: 1
Claim Your Seller Account
Sandpiper S07 Non-Metallic Ball Valve Diaphragm Pump
$1,599.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Sandpiper S07 Non-Metallic Ball Valve Diaphragm Pump is an air-powered double diaphragm pump designed for standard duty applications in wastewater handling. With a maximum flow rate of 23 gpm, this pump features non-metallic wetted materials such as Nylon, Polypropylene, and PVDF, ensuring compatibility with waste water environments. The pump's design includes Ball and Trihedral check valves for efficient operation and solids handling capability of up to 0.15 inches. Ideal for institutional and government buyers seeking reliable and compliant diaphragm pumps.
Product Specifications
Specifications Check Valve Seat
Nylon | Polypropylene | PVDF
Specifications Check Valve Type
Ball | Trihedral
Specifications Design Level
1
Specifications Displacement Per Stroke
0.026 gal | 0.098 lit
Specifications Elastomers
Santoprene/Buna | Santoprene/Santoprene | Virgin PTFE - Santoprene Backup Viton® | Virgin PTFE - Santoprene Backup/Virgin PTFE
Specifications Inlet Size
3/4" NPT-F (BSP)
Specifications Max Flow Rate
0 - 23 gpm | 0 - 87 lpm
Specifications Non Wetted Material
Polypropylene with PTFE hardware
Specifications Outlet Size
1 1/2" NPT-M (BSP)
Specifications Porting Position
ANSI Flange | Bottom Dual Porting (BSP) | Bottom Dual Porting (NPT) | Dual Porting (BSP) | Dual Porting (NPT) | Top Dual Porting (BSP) | Top Dual Porting (NPT)
Specifications Pump Style
Standard
Specifications Solids Handling
0.15 in | 4 mm
Specifications Type
Air Powered Double Diaphragm Pump | Pumps - Air Operated Diaphragm | Pumps - AOD Non-Metallic | Pumps - Sandpiper Standard Duty | Pumps - Sealless
Specifications Wetted Moc
Nylon | Polypropylene | PVDF
Category 6
Standard Duty Diaphragm Pumps
