Sandpiper S20 Evolution Metallic Ball Valve Diaphragm Pump
Sandpiper S20 Evolution Metallic Ball Valve Diaphragm Pump
SKU:PRO-5ad25e
Reliable Sandpiper S20 Evolution Diaphragm Pump for water and wastewater applications. Stainless steel construction with Viton elastomers. Max flow rate: 150 gpm.
Regular price
$1,899.99
Regular price
Sale price
$1,899.99
Unit price
per
Initiate Order
Sandpiper S20 Evolution Metallic Ball Valve Diaphragm Pump
$1,899.99
Quantity: 1
Claim Your Seller Account
Sandpiper S20 Evolution Metallic Ball Valve Diaphragm Pump
$1,899.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Sandpiper S20 Evolution Metallic Ball Valve Diaphragm Pump is a top-performing, air-powered double diaphragm pump designed for standard duty applications. With a stainless steel wetted M.O.C., Viton elastomers, and PTFE check valve seat, it ensures reliable and efficient operation. This pump features a maximum flow rate of 150 gpm, solid handling capacity of 0.25 inches, and a lightweight design at 95 lbs. Ideal for water, wastewater, and utility usage, meeting industry standards for quality and durability.
Product Specifications
Specifications Check Valve Seat
PTFE
Specifications Check Valve Type
Ball
Specifications Design Level
1
Specifications Discharge Pipe Size Internal
2" BSPT Tapered | 2" NPT
Specifications Displacement Per Stroke
0.42 gal | 1.59 lit
Specifications Elastomers
Viton®/Viton®
Specifications Intake Pipe Size Internal
2" BSPT Tapered | 2" NPT
Specifications Max Flow Rate
0 - 150 gpm | 0 - 567 lpm
Specifications Non Wetted Material
Painted Aluminum
Specifications Porting Position
NPT Threads
Specifications Pump Style
Standard
Specifications Solids Handling
0.25 in | 6 mm
Specifications Type
Air Powered Double Diaphragm Pump | Pumps - Air Operated Diaphragm | Pumps - AOD - Ball Valve - Top Ported | Pumps - Sandpiper Standard Duty
Specifications Weight
95 lbs | 43 kg
Specifications Wetted Moc
Stainless Steel
Category 6
Standard Duty Diaphragm Pumps
