The Scaletron VMF-90D Volumetric Screw Feeder with Vibratory Agitator is designed for precise and efficient dispensing of dry polymers in water treatment, wastewater, and chemical processing applications. Constructed with high-quality 304 stainless steel, it features a gear-driven auger mechanism with a 1.5 cu. ft. hopper capacity. This feeder offers a feed rate range of 0.77 to 7.73 ft³ per hour with 1% volume accuracy, ensuring consistent performance. The integrated 'Loss in Weight' system option provides gravimetric feeding capabilities for enhanced control. With its rugged construction and advanced controls, this feeder is a reliable solution for industrial settings.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Chemicals Chemicals
Feeder and scale are designed to accurately dispense:Aluminum sulfate (alum), calcium hydroxide (hydrated lime), carbon, ferric and ferrous sulfate, magnesium hydroxide, polymers, potassium, soda ash, sodium sulfite and thiosulfate, and other dry powders or pelletized materials
Options Options
Integrated "Loss in Weight" measurement system with four (4) load cells and Model 1020-1 5 Digit Scale ControllerExplosion proof motorPneumatic vibratory agitatorRemovable lidAdapter lidFeeder standProgrammable controller module stand
Power Alternating Current Ac Voltage
115 V | 230 V
Power Current
4 A
Power Frequency
50 Hz | 60 Hz
Specifications Accuracy
1% of volume
Specifications Ambient Temperature Limit
10 to 40 ºC
Specifications Available Motors
Explosion proof - 1/2 HP motor and gearing
Specifications Construction
304 Stainless Steel
Specifications Controls
Remote location mountable, programmable SCR controller module with HMI screen in stainless steel NEMA 4X enclosure
Specifications Control Input Current
4 to 20 mA
Specifications Direct Current Dc Voltage
90 V
Specifications Feed Rate Per Hour
0.77 to 7.73 ft³
Specifications Feed Screw
1.5" diameter open helix feed screw in 304 stainless steel
Specifications Hopper Capacity
1.5 ft³
Specifications Industry Standards
European Conformity (CE)
Specifications Motor Type
Right-angle geared, TENV 90 VDC, Washguard® motor 1/2 HP, 83 RPM
Specifications Optional Vibratory Agitator
Electric (Pneumatic is optional)
Specifications Overwind Helix
Concentric overwind material conditioning auger in 304 stainless steel
Specifications Warranty
2 Year Full Warranty on All Feeders
Standard Features Standard Features
Rugged, corrosion resistant 304 stainless steel constructionBuilt-in 1.5 cu. ft. gravity fed hopper with maintenance access hatch and integrated load cell attachment pointStainless steel, 1.5" diameter open helix feed screwStandard concentric material conditioning overwind augerElectric vibratory hopper agitator/material conditionerRemote location mounted, programmable SCR motor controller with HMI screen in water and dust proof NEMA 4X stainless enclosure90 VDC right-angle geared, wash down motor
Specifications Specifications
The Volumetric Screw Feeder with Vibratory Agitator must have rugged stainless steel frame. The feeder shall include a heavy-duty, gear driven auger metering mechanism with a stainless steel auger, concentric helical overwind auger and built-in stainless steel gravity fed hopper. All hardware shall be stainless steel. A programmable SCR controller module with HMI screen must be remote location mountable and housed in a water and dust proof NEMA 4X, UL approved enclosure. Auger shall be powered by a 1/2 HP DC motor and have integrated electric vibratory agitator/material conditioner.Feeder shall be a Model VMF-90D⢠as manufactured by Scaletron⢠Industries Ltd., Plumsteadville, PA.Options for "Loss of Weight System":The optional "Loss in Weight" measurement system for gravimetric feeding shall include four (4) NTEP approved stainless steel shear beam cells and stainless steel leveling bolts. A variety of scale indicators and controllers are available.
