Seal Fast Brass 1/4 inch Quick Connect Socket, Industrial Interchange, 2.30 in Length

Name: Seal Fast Brass 1/4 inch Quick Connect Socket, Industrial Interchange, 2.30 in Length
Brand: Seal Fast, Inc.
SKU: COU-e7b8a2
Price: 49.99 USD
Availability: OutOfStock

SKU:COU-e7b8a2

Reliable Seal Fast Brass 1/4in Quick Connect Socket for MIL-4109C Systems, featuring industrial interchange and easy pull-to-connect design.

$49.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The Seal Fast Brass Semi-Auto Industrial Interchange Quick Connect Socket is a reliable coupler that shuts off when disconnected, ideal for use in MIL-4109C Systems. This socket, with a 1/4 inch body size and end size, is constructed from durable brass, ensuring longevity and performance. Its easy pull-to-connect design enables instantaneous connection of air lines, operating within a temperature range of 0 to 176 ºF and a working pressure of 0 to 300 psi. With a 4-ball design and Buna-N seal material, this quick connect socket offers secure, efficient, and compliant pneumatic connection solutions.

Product Specifications

Specifications Body Size

1/4 in

Specifications Design

4 Ball

Specifications End Size

1/4 in. Shank

Specifications Material

Brass

Specifications Overall Diameter

0.98 in

Specifications Overall Length

2.30 in

Specifications Seal Material

Buna-N

Specifications Style

Semi-Auto Industrial Interchange

Specifications Temperature Range

0 to 176 ºF

Specifications Units Per Package

Specifications Working Pressure

0 to 300 psi

Seal Fast Brass 1/4 inch Quick Connect Socket, Industrial Interchange, 2.30 in Length
