Sealtite Type EFST - Flexible All Purpose Liquid Tight Metal Conduit (LFMC)
Sealtite Type EFST - Flexible All Purpose Liquid Tight Metal Conduit (LFMC)
SKU:LIQ-7ca4d3
Sealtite Type EFST Flexible Metal Conduit - Reliable liquid-tight raceway for wiring applications, IP 67 rated, ideal for general construction.
Regular price
$349.99
Regular price
Sale price
$349.99
Unit price
per
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.


The Sealtite Type EFST Flexible Liquid Tight Metal Conduit is a reliable solution for wiring applications, featuring a hot dipped zinc galvanized steel core with a PVC outer jacket. This conduit provides a liquid-tight raceway for electrical conductors, offering superior protection in environments where agency approvals are not required. With an IP 67 rating when used with approved end connectors, it ensures optimal performance. Suitable for a temperature range of -4ºF to +176ºF, this conduit is designed to meet the demanding needs of general construction grade applications.
Product Specifications
Application 0
Designed for General Construction Grade ApplicationsTemperature Range: -4ºF to +176ºF (-20ºC to +80ºC)
Installation 0
Conduit used with standard liquid-tight connector for easy installation. IP 67 Rated when installed with approved connectors.Delivers superior wiring protection where agency approvals are not required.Manufactured in a full range of trade sizes from 1/4" through 6". Conduit sizes 2-1/2", 3", 3-1/2", and 4" are Type UA/EFST.Smooth appearing jacket for exposed applications.Rated for temperature range of -4ºF to +176ºF (20ºC to +80ºC).Provides liquid-tight raceway for electrical conductors.
Specifications Approx Inside Bend Radius
16 in | 406.4 mm
Specifications Approx Weight Per 100 Ft
314 lbs | 142.43 kg
Specifications Color
GRAY
Specifications Core Material
Galvanized Steel
Specifications Cross Reference
28505 | LA-350 | LT-350
Specifications Electrical Trade Size
3-1/2 in | 91 mm
Specifications Industry Certifications
RoHS WEEE
Specifications Ingress Protection Ip Rating
Ingress Protection (IP) 66/67
Specifications Inside Diameter
3.500 to 3.540 in | 88.900 to 89.916 mm
Specifications Jacket Benefits
Liquid Tight
Specifications Jacket Material
Polyvinyl Chloride (PVC)
Specifications Length
100 ft | 30.48 m
Specifications Optional Colors
Black
Specifications Outside Diameter
3.960 to 4.000 in | 100.584 to 101.600 mm
Specifications Packaging
Standard Coils
Specifications Type
EFST
