Sealtite Type EFST Flexible Metal Conduit 3" x 25ft

Name: Sealtite Type EFST Flexible Metal Conduit 3" x 25ft
Brand: Anamet Electrical, Inc.
SKU: LIQ-85ed80
Price: 99.99 USD
Availability: OutOfStock

SKU:LIQ-85ed80

Durable Sealtite Type EFST Flexible Metal Conduit for secure and flexible wiring. IP 67 rated with RoHS WEEE certification.

$99.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The Sealtite Type EFST Flexible Metal Conduit is a durable solution for wiring, featuring a hot dipped zinc galvanized steel core with a PVC outer jacket. This conduit offers a flexible and liquid-tight raceway suitable for general construction grade applications. With an IP 67 rating and RoHS WEEE certification, it ensures superior wiring protection where agency approvals are not required. Easily installed with standard liquid-tight connectors, this conduit provides a reliable and secure electrical conductor solution for a wide range of applications.

Product Specifications

Application 0

Designed for General Construction Grade ApplicationsTemperature Range: -4ºF to +176ºF (-20ºC to +80ºC)

Installation 0

Conduit used with standard liquid-tight connector for easy installation. IP 67 Rated when installed with approved connectors.Delivers superior wiring protection where agency approvals are not required.Manufactured in a full range of trade sizes from 1/4" through 6". Conduit sizes 2-1/2", 3", 3-1/2", and 4" are Type UA/EFST.Smooth appearing jacket for exposed applications.Rated for temperature range of -4ºF to +176ºF (20ºC to +80ºC).Provides liquid-tight raceway for electrical conductors.

Specifications Approx Inside Bend Radius

15 in | 381 mm

Specifications Approx Weight Per 100 Ft

255 lbs | 115.67 kg

Specifications Color

GRAY

Specifications Core Material

Galvanized Steel

Specifications Cross Reference

28105 | LA-18 | LT-18

Specifications Electrical Trade Size

3 in | 78 mm

Specifications Industry Certifications

RoHS WEEE

Specifications Ingress Protection Ip Rating

Ingress Protection (IP) 66/67

Specifications Inside Diameter

3.070 to 3.100 in | 77.978 to 78.740 mm

Specifications Jacket Benefits

Liquid Tight

Specifications Jacket Material

Polyvinyl Chloride (PVC)

Specifications Length

25 ft | 7.62 m

Specifications Optional Colors

Black

Specifications Outside Diameter

3.460 to 3.500 in | 87.884 to 88.900 mm

Specifications Packaging

Standard Package

Specifications Type

EFST

Sealtite Type EFST Flexible Metal Conduit 3" x 25ft
