Sealtite Type EFST Liquid Tight Metal Conduit

Name: Sealtite Type EFST Liquid Tight Metal Conduit
Brand: Anamet Electrical, Inc.
SKU: LIQ-acfb94
Price: 249.99 USD
Availability: OutOfStock

SKU:LIQ-acfb94

Flexible, liquid-tight metal conduit for superior wiring protection in diverse environments.

$249.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The Sealtite Type EFST Flexible All Purpose Liquid Tight Metal Conduit offers a reliable, liquid-tight raceway solution for wiring. Constructed from hot-dipped zinc galvanized steel core with a PVC outer jacket, this conduit ensures durability and flexibility. Designed for General Construction Grade Applications, it features an IP 67 rating when used with approved connectors, providing superior wiring protection. With a temperature range of -4ºF to +176ºF, this conduit is suitable for various environments. RoHS WEEE certified and compliant with industry standards, this conduit is an ideal choice for applications not requiring agency approvals.

Product Specifications

Application 0

Designed for General Construction Grade ApplicationsTemperature Range: -4ºF to +176ºF (-20ºC to +80ºC)

Installation 0

Conduit used with standard liquid-tight connector for easy installation. IP 67 Rated when installed with approved connectors.Delivers superior wiring protection where agency approvals are not required.Manufactured in a full range of trade sizes from 1/4" through 6". Conduit sizes 2-1/2", 3", 3-1/2", and 4" are Type UA/EFST.Smooth appearing jacket for exposed applications.Rated for temperature range of -4ºF to +176ºF (20ºC to +80ºC).Provides liquid-tight raceway for electrical conductors.

Specifications Approx Inside Bend Radius

9.5 in | 241.3 mm

Specifications Approx Weight Per 100 Ft

182 lbs | 82.55 kg

Specifications Color

GRAY

Specifications Core Material

Galvanized Steel

Specifications Cross Reference

27105 | LA-17 | LT-17

Specifications Electrical Trade Size

2-1/2 in | 63 mm

Specifications Industry Certifications

RoHS WEEE

Specifications Ingress Protection Ip Rating

Ingress Protection (IP) 66/67

Specifications Inside Diameter

2.480 to 2.505 in | 62.992 to 63.627 mm

Specifications Jacket Benefits

Liquid Tight

Specifications Jacket Material

Polyvinyl Chloride (PVC)

Specifications Length

100 ft | 30.48 m

Specifications Optional Colors

Black

Specifications Outside Diameter

2.840 to 2.875 in | 72.136 to 73.025 mm

Specifications Packaging

Standard Coils

Specifications Type

EFST

Sealtite Type EFST Liquid Tight Metal Conduit
