SEALTITE Type FG NSF Certified Bacteria Inhibiting Conduit

Name: SEALTITE Type FG NSF Certified Bacteria Inhibiting Conduit
Brand: Anamet Electrical, Inc.
SKU: LIQ-6a1daa
Price: 189.99 USD
Availability: OutOfStock

SKU:LIQ-6a1daa

NSF Certified liquid-tight conduit inhibits bacteria growth, ideal for food-grade applications. Easily cleanable jacket for hygienic environments.

$189.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

SEALTITE Type FG Conduit is the only NSF Certified liquid-tight conduit designed for food-grade applications and washdown areas. Compliant with FDA CFR21 and NSF 51 standards, the thermoplastic PVC jacket inhibits bacteria growth, ensuring a hygienic environment. With a full range of trade sizes available, easy installation with standard connectors, and the ability to withstand cleaning with bleach without jacket degradation, this conduit is ideal for food processing facilities, meat and poultry packing plants, pharmaceutical manufacturers, and other specialized applications.

Product Specifications

Application 0

Special purpose food equipment or devices. Wash down areas. Meat packing facilities Restaurants Food processing facilities Poultry packing facilities Pharmaceutical manufacturers

Places Of Interest 0

Food equipment or devices NSF/ ANSI 169Food Equipment Manufacturers SIC 3556Meat Packing SIC 2011 NAICS 311613Poultry SIC 2015 NAICS 311615Pharmaceuticals SIC 2834 NAICS 325412

Specifications Approx Inside Bend Radius

4.0 in | 101.6 mm

Specifications Approx Weight Per 100 Ft

51 lbs | 23.13 kg

Specifications Core Material

Galvanized Steel

Specifications Cross Reference

131039 | 131049 | LTFG-13 | SZ04-30-00 | UL NSF S

Specifications Electrical Trade Size

1 in | 27 mm

Specifications Industry Certifications

NSF Component | RoHS WEEE

Specifications Ingress Protection Ip Rating

Ingress Protection (IP) 66/67

Specifications Inside Diameter

1.030 to 1.055 in | 26.162 to 26.797 mm

Specifications Jacket Benefits

Liquid Tight

Specifications Jacket Material

Polyvinyl Chloride (PVC)

Specifications Naed Pin

35531

Specifications Outside Diameter

1.290 to 1.315 in | 32.766 to 33.401 mm

Specifications Packaging

Standard Carton

Specifications Standard Length

100 ft | 30.48 m
