SEALTITE Type MTC Machine Tool Conduit LFMC - 3/4'' x 100ft - Black PVC Jacket
SEALTITE Type MTC Machine Tool Conduit LFMC - 3/4'' x 100ft - Black PVC Jacket
SKU:LIQ-0350ea
Flexible, liquid-tight SEALTITE Type MTC Conduit for industrial wiring, featuring zinc galvanized steel core, PVC jacket, and IP67 rating. RoHS/WEEE certified.
Regular price
$189.99
Regular price
Sale price
$189.99
Unit price
per
Initiate Order
SEALTITE Type MTC Machine Tool Conduit LFMC - 3/4'' x 100ft - Black PVC Jacket
$189.99
Quantity: 1
Claim Your Seller Account
SEALTITE Type MTC Machine Tool Conduit LFMC - 3/4'' x 100ft - Black PVC Jacket
$189.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The SEALTITE Type MTC Machine Tool Conduit is a versatile solution for creating flexible and liquid-tight raceways for wiring in industrial settings. Constructed with a hot-dipped zinc galvanized steel core and a PVC outer jacket, this conduit ensures superior protection and durability. It is IP 67 rated when used with approved connectors, making it ideal for applications where agency approvals are not required. With a smooth jacket for exposed applications and an extra-flexible design, this conduit is suitable for machine centers and robotics, featuring an operating temperature range of -4°F to +140°F. RoHS and WEEE certifications attest to its compliance with environmental standards.
Product Specifications
Application 0
Extra Flexible. For Use in Machine Centers and RoboticsTemperature Range: -4°F to +140°F (-20°C to +60°C)
Installation 0
Conduit used with standard liquid-tight connector for easy installation. IP 67 Rated when installed with approved connectors.Delivers superior wiring protection where agency approvals are not required.Manufactured in a full range of trade sizes from 3/8" through 2".Smooth appearing jacket for exposed applications. Rated for temperature range of -4ºF to +140ºF (-20ºC to +60ºC).Provides liquid-tight raceway for electrical conductors.
Specifications Approx Inside Bend Radius
2.5 in | 63.5 mm
Specifications Approx Weight Per 100 Ft
24 lbs | 10.89 kg
Specifications Color
BLACK
Specifications Core Material
Galvanized Steel
Specifications Cross Reference
89221 | MTLT | MTLT-3/4 | VJC-12
Specifications Electrical Trade Size
3/4 in | 21 mm
Specifications Industry Certifications
RoHS WEEE
Specifications Ingress Protection Ip Rating
Ingress Protection (IP) 66/67
Specifications Inside Diameter
0.815 to 0.835 in | 20.701 to 21.209 mm
Specifications Jacket Benefits
Liquid Tight
Specifications Jacket Material
Polyvinyl Chloride (PVC)
Specifications Length
100 ft | 30.48 m
Specifications Outside Diameter
1.009 to 1.034 in | 25.629 to 26.264 mm
Specifications Packaging
Standard Carton
Specifications Type
MTC
