Sealtite Type OR Liquid-Tight Metal Conduit (1 inch, 400ft)
Sealtite Type OR Liquid-Tight Metal Conduit (1 inch, 400ft)
SKU:LIQ-882e28
Sealtite Type OR Liquid-Tight Metal Conduit - Oil Resistant, IP 67 Rated, RoHS WEEE Certified, Ideal for Harsh Environments
Regular price
$599.99
Regular price
Sale price
$599.99
Unit price
per
Initiate Order
Sealtite Type OR Liquid-Tight Metal Conduit (1 inch, 400ft)
$599.99
Quantity: 1
Claim Your Seller Account
Sealtite Type OR Liquid-Tight Metal Conduit (1 inch, 400ft)
$599.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Sealtite Type OR Liquid-Tight Flexible Metal Conduit offers unparalleled protection for wiring in industrial environments exposed to cutting oils. Featuring a thermoplastic PVC jacket and a hot-dipped zinc galvanized steel core, this conduit is resilient against oil and liquid ingress. With an IP 67 rating and RoHS WEEE certification, it ensures reliable performance without the need for agency approvals. Ideal for temperature ranges from -9ºF to +221ºF, it guarantees a liquid-tight raceway for electrical conductors, making it a durable and secure choice for demanding applications.
Product Specifications
Application 0
Where Exposure to Cutting Oils OccurTemperature Range: -9ºF to +221ºF (-23ºC to +105ºC)
Installation 0
Conduit used with standard liquid-tight connector for easy installation. IP 67 Rated when installed with approved connectors.Delivers superior wiring protection where agency approvals are not required.Manufactured in a full range of trade sizes from 3/8" through 4".Smooth appearing jacket for exposed applications.Rated for temperature range of -9ºF to +221ºF (-23ºC to +105ºC).Provides liquid-tight raceway for electrical conductors.
Specifications Approx Inside Bend Radius
4.0 in | 101.6 mm
Specifications Approx Weight Per 100 Ft
51 lbs | 23.13 kg
Specifications Color
BLACK
Specifications Core Material
Galvanized Steel
Specifications Cross Reference
LOR-13
Specifications Electrical Trade Size
1 in | 27 mm
Specifications Industry Certifications
RoHS WEEE
Specifications Ingress Protection Ip Rating
Ingress Protection (IP) 66/67
Specifications Inside Diameter
1.030 to 1.055 in | 26.162 to 26.797 mm
Specifications Jacket Benefits
Liquid Tight | Oil Resistant
Specifications Jacket Material
Polyvinyl Chloride (PVC)
Specifications Length
400 ft | 121.92 m
Specifications Note
Sizes above 2" available on special order.Type OR-H available as special with heavy plated steel core and integral bonding wire.
Specifications Optional Colors
Gray
Specifications Outside Diameter
1.290 to 1.315 in | 32.766 to 33.401 mm
Specifications Packaging
Small Reels
Specifications Type
OR
