Series 250 I Beam Tow Trolley for Round Cable
Series 250 I Beam Tow Trolley for Round Cable
SKU:CRA-3f5070
Enhance crane control with our Series 250 I Beam Tow Trolley - reliable, safe, and efficient.
Regular price
$129.99
Regular price
Sale price
$129.99
Unit price
per
Initiate Order
Series 250 I Beam Tow Trolley for Round Cable
$129.99
Quantity: 1
Claim Your Seller Account
Series 250 I Beam Tow Trolley for Round Cable
$129.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Series 250 I Beam Tow Trolley for Round Cable is designed to provide smooth and efficient towing functionality for crane control applications. Crafted with Zinc Plated steel, it features anti-lift rollers for enhanced safety and stability. With a weight capacity of 95 lb and a speed capability of 250 fpm, this trolley ensures reliable performance. The steel flanged main rollers and precise dimensions of the saddle guarantee optimal cable management. Compliant with industry standards, this trolley is a robust solution for cable festoon systems on Series 250 I Beams.
Product Specifications
Specifications Anti Lift Rollers
Steel Diameter 1.38 in
Specifications Cable Window Height
0.4 in
Specifications Cable Window Width
6.7 in
Specifications Load
95 lb
Specifications Main Rollers
Steel Flanged Diameter 1.58 in
Specifications Material
Zinc Plated
Specifications Saddle Diameter
4 in
Specifications Saddle Width
8 in
Specifications Speed
250 fpm
Specifications Unit Length
11 1/8 in
Specifications Weight
15.0 lb
