Series 450 Heavy Duty I Beam Running Gear for S Beams
Series 450 Heavy Duty I Beam Running Gear for S Beams
SKU:CRA-8b1ebc
Durable Series 450 Running Gear for S Beams with steel main rollers & flanged anti-lift rollers for smooth & precise crane movement.
Regular price
$399.99
Regular price
Sale price
$399.99
Unit price
per
Initiate Order
Series 450 Heavy Duty I Beam Running Gear for S Beams
$399.99
Quantity: 1
Claim Your Seller Account
Series 450 Heavy Duty I Beam Running Gear for S Beams
$399.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Series 450 Heavy Duty I Beam Running Gear for S Beams is a robust solution designed for seamless overhead crane operations. Featuring steel main rollers with flanged anti-lift rollers, this running gear ensures smooth movement and precise positioning of heavy loads. With a maximum load capacity of 1100 lb and a main roller diameter of 4 inches, it is built for high-performance in demanding industrial environments. The galvanized steel construction and sealed ball bearings enhance durability and reliability, even in extreme operating temperatures ranging from -22 to 220 °F. Convenient independent side shield removal adds to its ease of maintenance, making it an ideal choice for efficient material handling applications.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Specifications Beam Size
S6 x 17.25 in
Specifications Main Roller Diameter
4 in | 100 mm
Specifications Maximum Load
1100 lb | 500 kg
Specifications Operating Temperature
-22 to 220 ºF
Specifications Running Gear Type
Steel Main Rollers, Flanged, with Anti-Lift Rollers
Specifications Speed
500 fpm
Specifications Weight
38.5 lb | 17.5 kg
