Series 450 Steel Running Gear for W Beams
Series 450 Steel Running Gear for W Beams
SKU:CRA-b8df4d
Enhance your crane system with Series 450 Steel Running Gear for W Beams. Durable, smooth operation, ideal for heavy-duty use.
Regular price
$349.99
Regular price
Sale price
$349.99
Unit price
per
Initiate Order
Series 450 Steel Running Gear for W Beams
$349.99
Quantity: 1
Claim Your Seller Account
Series 450 Steel Running Gear for W Beams
$349.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Upgrade your crane system with the Series 450 Steel Running Gear designed for W Beams. This heavy-duty running gear features hardened steel main rollers with precision ball bearings, zinc plated horizontal guide and anti-lift rollers for smooth operation. With a maximum load capacity of 450 lb and a main roller diameter of 2.5 inches, this running gear ensures reliable performance in a wide operating temperature range from -22 to 220 °F. The independent side shield removal design enhances maintenance convenience, making it ideal for industrial applications where durability and efficiency are essential.
Product Specifications
Specifications Beam Size
W8 x 10 in
Specifications Main Roller Diameter
2.5 in | 62 mm
Specifications Maximum Load
450 lb | 204 kg
Specifications Operating Temperature
-22 to 220 ºF
Specifications Running Gear Type
Steel Main Rollers, Crowned, with Horizontal Guide & Anti-Lift Rollers
Specifications Speed
500 fpm
Specifications Weight
27.3 lb | 12.4 kg
