The Series 55 Double Flanged Valves ANSI are meticulously engineered to meet the exacting demands of industrial applications. With a range of body materials including Cast Iron, Ductile Iron, Carbon Steel, Stainless Steel, and Bronze, these valves offer exceptional durability and corrosion resistance. The available disc materials such as Coated, Ductile Iron, Stainless Steel, and Aluminum Bronze ensure reliable performance in diverse environments. Featuring Stem Materials of K Monel and Stainless Steel, and Seat Materials like NBR, EPDM, Viton, Neoprene, Silicone, these valves guarantee superior sealing properties. Designed to ANSI standards, these valves are ideal for institutional and government procurement needs, combining quality construction with precise specifications for smooth operation.
Product Specifications
Specifications Available Disc Material
Aluminum Bronze | Coated | Ductile Iron | Stainless Steel
Specifications Available Packing Material
EPDM | NBR | Viton
Specifications Available Seat Material
EPDM | NBR | Neoprene | Silicone | Viton
Specifications Available Stem Material
K Monel | Stainless Steel
Specifications Body Material
Bronze | Carbon Steel | Cast Iron | Ductile Iron | Stainless Steel
Specifications C
539.5 mm
Specifications D
387 mm
Specifications H
817 mm
Specifications H1
343 mm
Specifications H2
369 mm
Specifications Hole Diameter
1 in
Specifications L
102 mm
Specifications Number Of Holes
16
Specifications O
23 mm
Specifications Size
400 - 16"
Specifications Standard
ANSI
Specifications Stem I
60 mm
Specifications Stem K
10 mm
Specifications Stem R
35 mm
Specifications Stem Y
5 mm
Specifications Top Flange To Iso 5211 Flange Type Iso 5211
F14
Specifications Top Flange To Iso 5211 M Diameter
18 mm
Specifications Top Flange To Iso 5211 N Number Of Tap Holes
4
Specifications Top Flange To Iso 5211 U
175 mm
Specifications Top Flange To Iso 5211 V
140 mm
Specifications Weight
96 kg
