The Series 6A Electro-Pneumatic Positioner is a high-precision control element featuring a supply pressure range of 20 to 102 psi, with an analog input signal of 4 to 20 mA. Designed with durable materials like fiberglass-reinforced polymer housing and stainless steel fasteners, this positioner provides reliable and accurate performance in temperatures ranging from -22 to +176°F. With approvals from FM, CSA, CE, and ATEX, this positioner is suitable for various industrial applications while meeting EMC requirements and NAMUR standards.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Specifications Air Consumption
<0.00035 scfm
Specifications Analog Input Signal Dc
4 to 20 mA
Specifications Available Approvals
FM, CSA, CE, ATEX
Specifications Bus Input Signal
HART, Foundation Fieldbus, Profibus PA Connections
Specifications Control Element Type
Piezoelectric
Specifications Emc Requirements
EN 61326/A1 Appendix A.1 | NAMUR NE21 August 98
Specifications Housing Fasteners Material
Stainless Steel
Specifications Housing Material
Fiberglass Reinforced Polymer with Metalized Coated interior for EMC protection
Specifications Hysteresis
<0.2 %
Specifications Input Signal 2 Conduit Entries
1/2" NPT (M20x1.5)
Specifications Positioner Mounting
VDI/VDE 3845 (NAMUR)
Specifications Position Indicator Material
ABS polymer
Specifications Protection Class
NEMA 4,4x and IP66
Specifications Repeatability
0.32 %
Specifications Resolution
<0.05 %
Specifications Supply Input Signal
1/4" NPT (G 1/4")
Specifications Supply Pressure
20 to 102 psi | 1.4 to 7 bar
Specifications Temperature Range
-22 to +176 ºF | -30 to +80 ºC
Specifications Weight
2.0 lbs | 0.9 kg
