Series 720 Hi-Rel Single Pin Connector Cable Assembly
Series 720 Hi-Rel Single Pin Connector Cable Assembly
SKU:HIG-b67006
High voltage Series 720 Hi-Rel Single Pin Connector Cable Assembly for altitude up to 70,000 ft. and operating temperature -55 to 125 ºC. Reliable and compatible design for various receptacles.
Regular price
$129.99
Regular price
Sale price
$129.99
Unit price
per
Initiate Order
Series 720 Hi-Rel Single Pin Connector Cable Assembly
$129.99
Quantity: 1
Claim Your Seller Account
Series 720 Hi-Rel Single Pin Connector Cable Assembly
$129.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Series 720 Hi-Rel Single Pin Connector Cable Assembly is a high-quality solution for high voltage applications, with a voltage rating of 20 kVDC and current ratings of 10A, 4A, and 6A. Designed for altitude exposures up to 70,000 ft., this threaded coupling style assembly operates within a temperature range of -55 to 125 ºC, making it suitable for demanding environments. It is compatible with various receptacles, including LGH LI series and Reynolds C720 receptacles, offering flexibility and reliability in connectivity. The fluorosilicone insulator ensures optimal performance, meeting stringent industry standards.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Body Properties Coupling Nut Material
Plastic
Specifications Altitudereduced Pressure Rating
70,000 ft.
Specifications Assembly Type
Single-Ended Plug Cable Assembly
Specifications Coupling Style
Threaded
Specifications Current Rating
10 Amp | 4 Amp | 6 Amp
Specifications Export Classification
TBD
Specifications Lgh Compatibility
LGH 1I
Specifications Mating Compatibility
Mates all series 720 receptacles and all LGH LI series receptacles. Also mates Reynolds C720 receptacles RC1525 and 3RC1525; this combination will reduce the upper operating temperature from +125ºC to +95ºC
Specifications Operating Temperature
-55 to 125 ºC
Specifications Rohs Compliant
TBD
Specifications Sealed Receptacle
N/A
Specifications Series
720
Specifications Standardnon Standard
Non-standard Part
Specifications Test Voltage
25 kVDC at 70,000 ft. (simulated) at ambient temperature
Specifications Voltage Rating
20 kVDC
