The Series 720 In-Line Receptacle Connector is a high-performance solution for high voltage applications, with a voltage rating of 20 kVDC. Designed for reliability in demanding environments, this connector features a plastic insulator, brass contacts with gold finish, and a pressure differential rating of 1 ATM. Its silicone seal material ensures effective sealing and a maximum leak rate of 1 X 10-6 cc/sec. With a temperature range of -55 to 125°C and compatibility with LGH™ lead assemblies, this connector offers exceptional quality and performance for critical connections.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Body Properties Coupling Nut Material
Plastic
Contact Properties Contact Diameter
0.063 in | 1.6 mm
Contact Properties Contact Finish
Gold
Contact Properties Contact Material
Brass
Contact Properties Contact Type
Male
Dimensions A
1.025 in | 26.0 mm
Dimensions B
.510 in | 13.0 mm
Dimensions C
.812 in | 20.6 mm
Specifications Altitudereduced Pressure Rating
70,000 ft.
Specifications Assembly Type
Receptacle Bag Assembly
Specifications Coupling Style
Threaded
Specifications Current Rating
10 Amp | 4 Amp | 6 Amp
Specifications Export Classification
TBD
Specifications Insulator Material
Plastic
Specifications Lgh Compatibility
LGH 1I
Specifications Mating Compatibility
Mates all series 720 and LGH LI lead assemblies Also mates all 20 kVDC rated Reynolds C720 lead assemblies; this combination will reduce the upper operating temperature from +125ºC to +95ºC.
Specifications Maximum Leak Rate Helium
1 X 10-6 cc/sec
Specifications Operating Temperature
-55 to 125 ºC
Specifications Panel Mounting Style
Front or Rear Mount
Specifications Pressure Differential Rating
Sealed for 1 ATM
Specifications Rohs Compliant
TBD
Specifications Sealed Receptacle
No
Specifications Seal Material
Silicone
Specifications Series
720
Specifications Standardnon Standard
Standard Part
Specifications Test Voltage
25 kVDC at 70,000 ft. (simulated) at ambient temperature
Specifications Thread
.50â-20 UNF-1A
Specifications Voltage Rating
20 kVDC
