Series 730 Double-Ended High Voltage Cable Assembly
Series 730 Double-Ended High Voltage Cable Assembly
SKU:HIG-a861cd
High voltage cable assembly with 4-6 Amp current rating, -55 to 125°C temp range, and threaded coupling for secure connections.
Regular price
$129.99
Regular price
Sale price
$129.99
Unit price
per
Initiate Order
Series 730 Double-Ended High Voltage Cable Assembly
$129.99
Quantity: 1
Claim Your Seller Account
Series 730 Double-Ended High Voltage Cable Assembly
$129.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Series 730 Double-Ended High Voltage Cable Assembly is engineered for superior performance in demanding environments. With a current rating of 4 Amp to 6 Amp and a temperature range of -55 to 125°C, this assembly ensures reliable power transmission. It mates with various receptacles and offers insulation options of Silicone or Fluorosilicone. The threaded coupling style enhances secure connections, meeting stringent institutional procurement standards for durability and efficiency.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Body Properties Coupling Nut Material
Plastic
Specifications Altitudereduced Pressure Rating
70,000 ft.
Specifications Assembly Type
Double-Ended Plug Cable Assembly
Specifications Coupling Style
Threaded
Specifications Current Rating
4 Amp | 6 Amp
Specifications Export Classification
TBD
Specifications Insulator Material
Silicone or Fluorosilicone
Specifications Lgh Compatibility
LGH 1/2I
Specifications Mating Compatibility
Mates all series 730 & 830 receptacles and all LGH 1/2I series receptacles. Also mates Reynolds C730 receipt axles RC1505,2RC1505 and 3RC1505: this combination will reduce the upper operating temperature from +125ºC to +95ºC
Specifications Operating Temperature
-55 to 125 ºC
Specifications Rohs Compliant
TBD
Specifications Sealed Receptacle
N/A
Specifications Series
730
Specifications Standardnon Standard
Non-standard Part
Specifications Test Voltage
15 kVDC at 70,000 ft. (Simulated) at Ambient Temperature
Specifications Voltage Rating
10 kVDC
Specifications Wire Type
FEP
Wire Properties Accomodates Wire Diameter
0.080 in | 2.03 mm
Wire Properties Wire Pn
167-9543
