Series 830 Plug Kit Metal Coupling Nut - High Voltage Single Pin Connector
Series 830 Plug Kit Metal Coupling Nut - High Voltage Single Pin Connector
SKU:HIG-b64bf8
Series 830 Plug Kit for high voltage applications, 10 kVDC, 4-6 Amp, Fluorosilicone insulator, threaded coupling, LGH™ 1/2I compatible
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Initiate Order
Series 830 Plug Kit Metal Coupling Nut - High Voltage Single Pin Connector
$29.99
Quantity: 1
Claim Your Seller Account
Series 830 Plug Kit Metal Coupling Nut - High Voltage Single Pin Connector
$29.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Series 830 Plug Kit Metal Coupling Nut is a reliable high voltage connector designed for demanding environments. With a voltage rating of 10 kVDC, current ratings of 4 Amp and 6 Amp, and operating temperature range of -55 to 125 °C, this connector ensures secure and efficient power transfer. Its Fluorosilicone insulator material and threaded coupling style provide durability and ease of use. LGH™ 1/2I compatibility makes it ideal for various applications, while the metal coupling nut ensures robustness in connections.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Body Properties Coupling Nut Material
Metal | Plastic
Specifications Altitudereduced Pressure Rating
70,000 ft.
Specifications Assembly Type
Plug Bag Assembly
Specifications Coupling Style
Threaded
Specifications Current Rating
4 Amp | 6 Amp
Specifications Export Classification
TBD
Specifications Insulator Material
Fluorosilicone
Specifications Lgh Compatibility
LGH 1/2I
Specifications Operating Temperature
-55 to 125 ºC
Specifications Rohs Compliant
TBD
Specifications Sealed Receptacle
N/A
Specifications Series
830
Specifications Voltage Rating
10 kVDC
Specifications Wire Type
FEP
