The Series EVFL Double Flanged Long Valve is a premium-grade concentric butterfly valve designed for superior performance in industrial applications. With a vulcanized rubber lining and compliance with ISO 5752/EN 558 standards, this valve ensures optimal sealing and longevity. Available in sizes ranging from DN40 to 2000 (2" to 80"), and with design pressures up to 16 Bar/232 psi, it offers versatility and reliability. Choose from a variety of actuation options, body materials including stainless steel, and stem materials such as Duplex Stainless Steel. Ideal for isolating and regulating flow, this valve guarantees bi-directional tight shut off and meets various type approvals for quality assurance.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Specifications A
386 mm
Specifications Actuation Possibilities
Electric | Hydraulic | Manual | Pneumatic
Specifications Available Type Approvals
ABS | BV | DVGW | FM | GL | KIWA | LRS | RINA | RMRS | WRC
Specifications Body Material
Cast Iron
Specifications C
310 mm
Specifications D
308 mm
Specifications E
363 mm
Specifications F
25 mm
Specifications Flange Connections
ANSI Class 150 | JIS 10 | JIS 16 | JIS 5 | PN 10 | PN 16 | PN 6
Specifications G
50 mm
Specifications H Diameter
30 mm
Specifications Iso 5211
F14
Specifications K
140 mm
Specifications L
175 mm
Specifications Liner Material
Ethylene Propylene Diene Monomer (EPDM) Special Grade | Ethylene Propylene Diene Monomer (EPDM) Standard Grade | Fluoroelastomer Polymer (FPM) Viton | Nitrile Butadiene Rubber (NBR)
Specifications M Diameter
17 mm
Specifications N Number Of Holes
4
Specifications Shaft Material
Stainless Steel 1.4462
Specifications Size
DN400 - 16" | 400 mm
Specifications Standard
DIN
Specifications Stem Material
Aluminum Bronze | Duplex Stainless Steel 1.4462 | Martensitic Stainless Steel 1.4408
Specifications Valve Function
Isolating valve (on,off) and regulating valve | Regulating valve
Specifications Valve Shut Off Pressure
10 bar | 16 bar | 2.5 bar | 6 bar
Specifications Weight
165.0 kg
Specifications X
230 mm
Specifications Y
38 mm
