Series EVFL Double Flanged Long Valve - Butterfly Valve
Series EVFL Double Flanged Long Valve - Butterfly Valve
SKU:VAL-9f91b1
Premium Series EVFL Double Flanged Long Valve for industrial flow control
Regular price
$1,299.99
Regular price
Sale price
$1,299.99
Unit price
per
Initiate Order
Series EVFL Double Flanged Long Valve - Butterfly Valve
$1,299.99
Quantity: 1
Claim Your Seller Account
Series EVFL Double Flanged Long Valve - Butterfly Valve
$1,299.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Series EVFL Double Flanged Long Valve is a premium-grade concentric butterfly valve designed for superior performance and durability in industrial applications. With a robust construction featuring various material options such as Stainless Steel, Carbon Steel, and Ductile Iron, this valve ensures reliable operation even in demanding environments. It meets ISO 5752/EN 558 standards, offering precise control and tight shut off. Available in sizes DN40 - 2000, this valve can be actuated manually, electrically, pneumatically, or hydraulically. Whether as an isolating or regulating valve, the Series EVFL guarantees efficient flow control with minimal leakage, meeting the highest industry quality certifications.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Specifications A
686 mm
Specifications Actuation Possibilities
Electric | Hydraulic | Manual | Pneumatic
Specifications Available Type Approvals
ABS | BV | DVGW | FM | GL | KIWA | LRS | RINA | RMRS | WRC
Specifications Body Material
Bronze RG10 | Carbon Steel | GG25 Cast Iron | GGG40 Ductile Iron | Stainless Steel
Specifications C
430 mm
Specifications D
480 mm
Specifications E
560 mm
Specifications F
25 mm
Specifications Flange Connections
ANSI Class 150 | JIS 10 | JIS 16 | JIS 5 | PN 10 | PN 16 | PN 6
Specifications G
60 mm
Specifications H Diameter
46 mm
Specifications Iso 5211
F16
Specifications K
165 mm
Specifications L
210 mm
Specifications Liner Material
Ethylene Propylene Diene Monomer (EPDM) Special Grade | Ethylene Propylene Diene Monomer (EPDM) Standard Grade | Fluoroelastomer Polymer (FPM) Viton | Nitrile Butadiene Rubber (NBR)
Specifications M Diameter
21 mm
Specifications N Number Of Holes
4
Specifications Size
DN700 - 28" | 700 mm
Specifications Stem Material
Aluminum Bronze | Duplex Stainless Steel 1.4462 | Martensitic Stainless Steel 1.4408
Specifications Valve Function
Isolating valve (on,off) and regulating valve | Regulating valve
Specifications Valve Shut Off Pressure
10 bar | 16 bar | 2.5 bar | 6 bar
Specifications Weight
420.0 kg
Specifications X
535 mm
Specifications Y
128 mm
