Series EVFL Gear Operated Cast Iron Flanged Butterfly Valve
Series EVFL Gear Operated Cast Iron Flanged Butterfly Valve
SKU:VAL-df09b3
High-performance cast iron butterfly valve for industrial applications, DN450 (18") size, PN 6 pressure rating, robust construction.
Regular price
$849.99
Regular price
Sale price
$849.99
Unit price
per
Initiate Order
Series EVFL Gear Operated Cast Iron Flanged Butterfly Valve
$849.99
Quantity: 1
Claim Your Seller Account
Series EVFL Gear Operated Cast Iron Flanged Butterfly Valve
$849.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Series EVFL Gear Operated Cast Iron Flanged Butterfly Valve is designed for precision performance in industrial applications. With a size of DN450 (18") and a robust cast iron construction, this valve offers reliable isolating and regulating functions with shut off pressures ranging from 2.5 to 16 bar. Engineered to meet stringent DIN standards, this valve features an EPDM liner, stainless steel shaft, and multiple approvals including ABS, BV, and DVGW.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Specifications A
436 mm
Specifications Actuation Possibilities
Gear
Specifications Available Type Approvals
ABS | BV | DVGW | FM | GL | KIWA | LRS | RINA | RMRS | WRC
Specifications Body Material
Cast Iron
Specifications C
330 mm
Specifications D
334 mm
Specifications E
388 mm
Specifications F
25 mm
Specifications Flange Connections
PN 6
Specifications G
50 mm
Specifications H Diameter
30 mm
Specifications Iso 5211
F14
Specifications K
140 mm
Specifications L
175 mm
Specifications Liner Material
Ethylene Propylene Diene Monomer (EPDM)
Specifications M Diameter
17 mm
Specifications N Number Of Holes
4
Specifications Pressure
PN 6
Specifications Shaft Material
Stainless Steel 1.4462
Specifications Size
DN450 - 18" | 450 mm
Specifications Standard
DIN
Specifications Stem Material
Aluminum Bronze | Duplex Stainless Steel 1.4462 | Martensitic Stainless Steel 1.4408
Specifications Valve Function
Isolating valve (on,off) and regulating valve | Regulating valve
Specifications Valve Shut Off Pressure
10 bar | 16 bar | 2.5 bar | 6 bar
Specifications Weight
200.0 kg
Specifications X
285 mm
Specifications Y
53 mm
