Sethco Magnetic Drive Centrifugal Filter Systems - DPM Series
Sethco Magnetic Drive Centrifugal Filter Systems - DPM Series
SKU:FIL-aa0584
Reliable Sethco Magnetic Drive Centrifugal Filter Systems for corrosive liquid filtration. CPVC construction, magnetic drive, sealless pump, and diverse filtration rates. Ideal for electroplating, pharmaceutical, and more applications.
Regular price
$2,499.99
Regular price
Sale price
$2,499.99
Unit price
per
Initiate Order
Sethco Magnetic Drive Centrifugal Filter Systems - DPM Series
$2,499.99
Quantity: 1
Claim Your Seller Account
Sethco Magnetic Drive Centrifugal Filter Systems - DPM Series
$2,499.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Sethco Magnetic Drive Centrifugal Filter Systems in the DPM Series offer unparalleled leakproof operation and filtration rates ranging from 1 to 4500 GPH. Constructed with CPVC material, these systems are ideal for corrosive liquid filtration in applications such as electroplating, pharmaceuticals, and more. Each system features a polypropylene, magnetic drive, sealless centrifugal pump, ensuring long-term reliability. With standard and Kynar construction options, and a one-year warranty, these Sethco systems provide efficient and dependable filtration solutions.
Product Specifications
Filter Chamber Filter Chamber
CPVC filter chambers are standard on most systems. Kynar construction is available on some models. All chambers accept economical, standard open ended filter tubes or carbon filter tubes.
Filter Tubes Filter Tubes
Polypropylene, or Cotton, depending on application. Filter tubes are available for controlled filtration from 150 microns to 0.5 micron. Standard densities are coarse (50 microns), medium (25 microns), fine (15 microns), X-fine (10 microns), Special B (1-3 microns), and Special C (0.5 micron). All systems are supplied with 1 set of 15 micron polypropylene tubes.
Note Note
Kynar filter systems are provided with Kynar pipe and union to connect chamber inlet and outlet. No other accessories are provided.
Specifications Flow Rate
800 to 2400 gph | 3000 to 9000 lph
Specifications Height
36 " | 91 cm
Specifications Length
20 " | 51 cm
Specifications Manufacturer
Sethco
Specifications Material
CPVC
Specifications Max Operating Temperature
180 ºF | 82 ºC
Specifications Pump Model No
PM-1040NT-1T1
Specifications Quantity Of Filter Tubes In Chamber
8
Specifications Series
DPM
Specifications Size Of Filter Tubes In Chamber
8 Tubes - 10", 15 Micron
Specifications System Type
With Magnetic Drive Sealless Pump
Specifications Weight
90.0 lbs | 44.8 kg
Specifications Width
24 " | 61 cm
Warranty Warranty
One year warranty against defective parts and workmanship. See Form TC-01 for full warranty details. Always be specific about your application in order that proper materials may be furnished. Let Mefiag or an authorized distributor know: liquids being handled, gallons, temperature and pH.The standard warranty does not apply when equipment is used contrary to factory recommendations.Since the policy of Mefiag is one of continual improvement, were reserve the right to change design or materials at any time, without giving notice or creating any obligation to previous or future customers.
