Shamrock Controls 3-Pole AC Contactor with 7A Inductive Current
Shamrock Controls 3-Pole AC Contactor with 7A Inductive Current
SKU:CON-39a3f9
Reliable 3-Pole AC Contactor with 7A Inductive Current for Industrial Use
Regular price
$129.99
Regular price
Sale price
$129.99
Unit price
per
Initiate Order
Shamrock Controls 3-Pole AC Contactor with 7A Inductive Current
$129.99
Quantity: 1
Claim Your Seller Account
Shamrock Controls 3-Pole AC Contactor with 7A Inductive Current
$129.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Shamrock Controls 3-Pole AC Contactor features a maximum inductive current of 7A at 3-phase alternating current, making it ideal for heavy-duty industrial applications. With built-in auxiliary contacts, various coil voltage options, and a wide range of maximum horsepower support, this contactor ensures reliable performance and efficient electrical control. Designed for durability and compatibility, this product meets stringent industry standards for institutional procurement.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Auxiliary Contacts Built In Per Contactor Auxiliary Contacts Nor
1
Contactor Coils Contactor Coils
TX1-D2I1-B5 (TX1-D3-B5) : 24V, 50 HzTX1-D211-B6 (TX1-D3-B6) : 24V, 60 HzTX1-D211-B7 (TM-D3-B7) : 24V, 50/60 HzTX1-D211-CS (TX1-D3-C5) : 32V, 5O HzTX1-D211-C7 (TX1-D3-C7) : 32V, 50/60 HzTX1-D211-D5 (TX1-D3-D5) : 42V, 50 HzTX1-D211-D7 (TX1-D3-D7) : 42V, 50/60 HzTX1-D211-ES (TX1-D3-ES) : 48V, 5O HzTX1-D211-E6 (TX1-D3-E6) : 48V, 60 HzTX1-D211-E7 (TX1-D3-E7) : 48V, 50/60 HzTX1-D211-F5 (TX1-D3-F5) : 110V, 50 HzTX1-D211-F6 (TX1-D3-F6) : 110, 60 HzTX1-D211-F7 (TX1-D3-F7) : 110V, 50/60 HzTX1-D211-G6 (TX1-D3-G6) : 120V, 60 HzTX1-DZ11-G7 (TX1-D3-G7) : 120V, 50/60 HzTX1-D211-L6 (TX1-D3-L6) : 208V, 60 HzTX1-D211-M5 (TX1-D3-MS) : 220V, 50 HzTX1-D211-M6 (TX1-D3-M6) : 220V, 60 HzTX1-D211-M7 (TX1-D3-M7) : 220V, 50/60 HzTX1-D211-NS (TX1-D3-N5) : 415V, 50 HzTX1-D211-N6 (TX1-D3-N6) : 415V, 60 HzTX1-D211-N7 (TX1-D3-N7) : 415V, 50/60 HzTX1-D211-P5 (TX1-D3-P5) : 230V, 50 HzTX1-D211-P7 (TX1-D3-P7) : 230V, 50/60 HzTX1-D211-QS (TX1-D3-Q5) : 380V, 50 HzTX1-D211-Q6 (TX1-D3-Q6) : 380V, 60 HzTX1-D211-Q7 (TX1-D3-Q7) : 380V, 50/60 HzTX1-D211-R6 (TX1-D3-R6) : 440V, 60 HzTX1-D211-R7 (TX1-D3-R7) : 440V, 50/60 HzTX1-D211-56 (TX1-D3-S6) : 575V, 60 HzTX1-D211-S7 (TX1-D3-S7) : 575V, 50/60 HzTX1-D211-T6 (TX1-D3-T6) : 480V, 60 HzTX1-D211-T7 (TX1-D3-T7) : 480V, 50/60 HzTX1-D211-U5 (TX1-D3-U5) : 240V, 50 HzTX1-D211-U6 (TX1-D3-U6) : 240V, 60 HzTX1-D211-U7 (TX1-D3-U7) : 240V, 50/60 HzTX1-D211-V7 (TX1-D3-V7) : 400V, 50/60 HzTX1-D211-W6 (TX1-D3-W6) : 277V, 60 HzTX1-D2 11-X6 (TX1-D3-X6) : 600V, 60 Hz
Maximum Current Maximum 1 Phase Resistive Alternating Current Ac
25 A
Maximum Current Maximum 3 Phase Inductive Alternating Current Ac
7 A
Maximum Horsepower Hp Maximum Single Phase Power At 120 Volt V
0.5 hp
Maximum Horsepower Hp Maximum Single Phase Power At 230 Volt V
1 hp
Maximum Horsepower Hp Maximum Three Phase Power At 120 Volt V
2 hp
Maximum Horsepower Hp Maximum Three Phase Power At 230 Volt V
2 hp
Maximum Horsepower Hp Maximum Three Phase Power At 400 Volt V
5 hp
Maximum Horsepower Hp Maximum Three Phase Power At 600 Volt V
7.5 hp
Specifications Coil Voltage
277 V
Specifications Frequency
60 Hz
Specifications Type Of Auxiliary Contacts
Normally Closed | Normally Open
