Shamrock Controls 3 Pole Contactor with 38A Inductive Current
Shamrock Controls 3 Pole Contactor with 38A Inductive Current
SKU:CON-1881da
Reliable 3 Pole Contactor with 38A Inductive Current for industrial applications. Suitable for 60Hz frequency requirements.
Regular price
$149.99
Regular price
Sale price
$149.99
Unit price
per
Initiate Order
Shamrock Controls 3 Pole Contactor with 38A Inductive Current
$149.99
Quantity: 1
Claim Your Seller Account
Shamrock Controls 3 Pole Contactor with 38A Inductive Current
$149.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Shamrock Controls 3 Pole Contactor is designed for industrial applications requiring a maximum inductive current of 38A. With both Normally Closed and Normally Open auxiliary contacts, this contactor ensures reliable operation in various scenarios. It meets industry standards for alternating current (AC) operations and is suitable for 60Hz frequency requirements. Built to last and easy to install, this contactor offers optimal performance in demanding environments.
Product Specifications
Auxiliary Contacts Built In Per Contactor Auxiliary Contacts Nor
1
Contactor Coils Contactor Coils
TX1-D2I1-B5 (TX1-D3-B5) : 24V, 50 HzTX1-D211-B6 (TX1-D3-B6) : 24V, 60 HzTX1-D211-B7 (TM-D3-B7) : 24V, 50/60 HzTX1-D211-CS (TX1-D3-C5) : 32V, 5O HzTX1-D211-C7 (TX1-D3-C7) : 32V, 50/60 HzTX1-D211-D5 (TX1-D3-D5) : 42V, 50 HzTX1-D211-D7 (TX1-D3-D7) : 42V, 50/60 HzTX1-D211-ES (TX1-D3-ES) : 48V, 5O HzTX1-D211-E6 (TX1-D3-E6) : 48V, 60 HzTX1-D211-E7 (TX1-D3-E7) : 48V, 50/60 HzTX1-D211-F5 (TX1-D3-F5) : 110V, 50 HzTX1-D211-F6 (TX1-D3-F6) : 110, 60 HzTX1-D211-F7 (TX1-D3-F7) : 110V, 50/60 HzTX1-D211-G6 (TX1-D3-G6) : 120V, 60 HzTX1-DZ11-G7 (TX1-D3-G7) : 120V, 50/60 HzTX1-D211-L6 (TX1-D3-L6) : 208V, 60 HzTX1-D211-M5 (TX1-D3-MS) : 220V, 50 HzTX1-D211-M6 (TX1-D3-M6) : 220V, 60 HzTX1-D211-M7 (TX1-D3-M7) : 220V, 50/60 HzTX1-D211-NS (TX1-D3-N5) : 415V, 50 HzTX1-D211-N6 (TX1-D3-N6) : 415V, 60 HzTX1-D211-N7 (TX1-D3-N7) : 415V, 50/60 HzTX1-D211-P5 (TX1-D3-P5) : 230V, 50 HzTX1-D211-P7 (TX1-D3-P7) : 230V, 50/60 HzTX1-D211-QS (TX1-D3-Q5) : 380V, 50 HzTX1-D211-Q6 (TX1-D3-Q6) : 380V, 60 HzTX1-D211-Q7 (TX1-D3-Q7) : 380V, 50/60 HzTX1-D211-R6 (TX1-D3-R6) : 440V, 60 HzTX1-D211-R7 (TX1-D3-R7) : 440V, 50/60 HzTX1-D211-56 (TX1-D3-S6) : 575V, 60 HzTX1-D211-S7 (TX1-D3-S7) : 575V, 50/60 HzTX1-D211-T6 (TX1-D3-T6) : 480V, 60 HzTX1-D211-T7 (TX1-D3-T7) : 480V, 50/60 HzTX1-D211-U5 (TX1-D3-U5) : 240V, 50 HzTX1-D211-U6 (TX1-D3-U6) : 240V, 60 HzTX1-D211-U7 (TX1-D3-U7) : 240V, 50/60 HzTX1-D211-V7 (TX1-D3-V7) : 400V, 50/60 HzTX1-D211-W6 (TX1-D3-W6) : 277V, 60 HzTX1-D2 11-X6 (TX1-D3-X6) : 600V, 60 Hz
Maximum Current Maximum 1 Phase Resistive Alternating Current Ac
50 A
Maximum Current Maximum 3 Phase Inductive Alternating Current Ac
38 A
Maximum Horsepower Hp Maximum Single Phase Power At 120 Volt V
2 hp
Maximum Horsepower Hp Maximum Single Phase Power At 230 Volt V
5 hp
Maximum Horsepower Hp Maximum Three Phase Power At 120 Volt V
10 hp
Maximum Horsepower Hp Maximum Three Phase Power At 230 Volt V
10 hp
Maximum Horsepower Hp Maximum Three Phase Power At 400 Volt V
20 hp
Maximum Horsepower Hp Maximum Three Phase Power At 600 Volt V
25 hp
Specifications Frequency
60 Hz
Specifications Type Of Auxiliary Contacts
Normally Closed | Normally Open
