Shamrock Controls 30A 2-Pole Definite Purpose Contactor
Shamrock Controls 30A 2-Pole Definite Purpose Contactor
SKU:DPC-163ad3
Reliable Shamrock Controls 30A 2-Pole Definite Purpose Contactor for Motors, Lights & HVAC. Suitable for consumer & institutional applications.
Regular price
$49.99
Regular price
Sale price
$49.99
Unit price
per
Initiate Order
Shamrock Controls 30A 2-Pole Definite Purpose Contactor
$49.99
Quantity: 1
Claim Your Seller Account
Shamrock Controls 30A 2-Pole Definite Purpose Contactor
$49.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Shamrock Controls 30 Amp 2 Pole Definite Purpose Contactor is designed for precise control of Motors, Power Supplies, Hanging Elements, Lighting, HVAC Fans, and Compressors. With a resistive rating current of 30A and a coil voltage of 480V, this contactor is built for reliability and durability. It boasts a locked rotor current of 120A at 240/277V AC and meets stringent industry standards for performance and efficiency. Ideal for both consumer and institutional use.
Product Specifications
Coil Data Coil Voltage
480 V
Coil Data Duty Cycle
Continuous
Coil Data Frequency
50 Hz
Coil Data Minimum Initial Insulation Resistance
100 MΩ
Coil Data Normal Inrush Apparent Power
65 V·A
Coil Data Sealed Apparent Power
7.5 V·A
Environment Ambient Air Dampness Around The Device Relative Humi
45 to 85 %
Environment Ambient Air Temperature
40 to 65 ºC
Environment Coil Apply Voltage At 50 Hertz Hz Frequency
75 to 110 %
Environment Maximum Operating Altitude Above Sea Level
2000 m
Environment Operating Temperature
-5 to 55 ºC
Specifications Locked Rotor Per Pole Current At 240 Alternating
120 A
Specifications Number Of Poles
2
Technical Data Full Load Expected Life
200000 Operations
Technical Data Full Load Inductive Current
20 A
Technical Data Locked Rotor Per Pole Current At 480 Alternating
100 A
Technical Data Locked Rotor Per Pole Current At 600 Alternating
80 A
Technical Data Mechanical Alternating Current Ac Coil Operations
2 Million
Technical Data Minimum Contact Data At 120 Alternating Current V
3 A
Technical Data Resistive Rating Current
30 A
