Shamrock Controls 330A 3-Pole Contactors
Shamrock Controls 330A 3-Pole Contactors
SKU:CON-bde269
Reliable 330A 3-Pole Contactor for high-power applications, compliant with industry standards.
Regular price
$349.99
Regular price
Sale price
$349.99
Unit price
per
Initiate Order
Shamrock Controls 330A 3-Pole Contactors
$349.99
Quantity: 1
Claim Your Seller Account
Shamrock Controls 330A 3-Pole Contactors
$349.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Shamrock Controls 330A 3-Pole Contactor is a reliable solution for high-power applications, featuring a maximum inductive AC current of 330A. With a power rating of up to 250hp at 600V, this contactor is designed to meet the demands of industrial operations. Compliant with BSEN80947, IEC60947, and other international standards, it ensures safety and performance. The contactor is approved by CSA, IEC, and UL, making it suitable for various institutional procurement needs.
Product Specifications
Control Circuit Characteristics Average Consumption At 20 Degree
10 V·A
Control Circuit Characteristics Power Circuit Connection Tighten
1.2 N·m
Dimensions Diameter
M10
Dimensions Dimension A
206 mm
Dimensions Dimension B
206 mm
Dimensions Dimension B1
145 mm
Dimensions Dimension B2
375 mm
Dimensions Dimension C
220 mm
Dimensions Dimension G
154.5 mm
Dimensions Dimension G1
96 mm
Dimensions Dimension I
147 mm
Dimensions Dimension J
106 mm
Dimensions Dimension J1
120 mm
Dimensions Dimension L
147 mm
Dimensions Dimension M
181 mm
Dimensions Dimension P
48 mm
Dimensions Dimension Q
43 mm
Dimensions Dimension Q1
74 mm
Dimensions Dimension S
25 mm
Dimensions Dimension S1
44.5 mm
Dimensions Dimension Y
38 mm
Dimensions Dimension Z
20.5 mm
Dimensions Minimum Electrical Tolerance According To Breaking Ca
15 mm
Dimensions Minimum Electrical Tolerance According To Operating V
10 mm
Pole Characteristics Bar Size
30 x 5 mm
Pole Characteristics Bolt Diameter
10 mm²
Pole Characteristics Cable With Lug Size
240 mm
Pole Characteristics Maximum Power Rating At 200 Voltage
75 hp
Pole Characteristics Maximum Power Rating At 230 Voltage
100 hp
Pole Characteristics Maximum Power Rating At 480 Voltage
200 hp
Pole Characteristics Maximum Power Rating At 600 Voltage
250 hp
Pole Characteristics Rated Insulation Voltage
1500 V
Pole Characteristics Rated Operational Voltage
0 to 1000 V
Specifications Power Dissipation Per Pole For Ac 3 The Above Ope
31 W
